| Part number | Part name |
|---|---|
| AM1202-X | Motor Mount |
| AM1203-X | Battery Plate |
| AM1204X-ST | Chassis Plate |
| AM1206 | Front Nut |
| AM1207-X | Left Bulkhead |
| AT1201 | Steering Block Nut |
| AT1202 | Servo Post |
| AT1203 | Rear Beam |
| AT1204-X | Steering Block |
| AT1206 | Servo Plate Post |
| AT1207-X | Left Hub |
| AT1215 | Spur Nut |
| AT25-2 | Turnbuckle 39mm |
| DT1202 | Steering Washer |
| DT1211 | Side Spring Holder |
| DT1210 | Downstop Nut |
| ST1201-X | 3mm Ball Stud |
| ST1202-XS | Damper Rotor |
| ST1203-X | Downstop Rod |
| ST1204-X | Damper Case |
| ST1236 | Rear Spring Rod |
| ST1238 | Rear Spring Seat |
| ST1208-C4AL | Steering Block Post |
| ST1248 | Battery Plate Nut |
| ST1254 | LRC Seat |
| ST1255 | LRC Nut |
| ST1256 | LRC Rear Ball |
| ST1257 | LRC Front Ball |
| ST1211 | Spring Retainer |
| ST24-4.0 | 4.0mm Ball Stud |
| ST24 | 4.8x6mm Ball Stud |
| ST1260 | Tapered Spacer |
| P1215 | Foam Bumper |
| P13-4 | Ball Cup |
| P1213 | Ball Cup 4.0 mm |
| P14-2 | Body post |
| C1201-X | Servo Plate |
| C1203-X | Body Holder |
| C1204 | Bumper Plate |
| C1205-X | Suspension Plate |
| SPR12F-C1.1 | Front Spring C1.1 |
| SPR12XS-C1.0 | Side Spring C1.0 |
| SPR12XS-C0.8 | Side Spring C0.8 |
| SPR12XS-C1.2 | Side Spring C1.2 |
| SPR12XR-C1.0 | Rear Spring C1.0 |
| SPR12XR-C0.8 | Rear Spring C0.8 |
| SPR12XR-C1.2 | Rear Spring C1.2 |
| SPR05 | Body Clip |
| B156 | 3/16x5/16x1/8 Flanged Bearing |
| B168 | 1/4x3/8x1/8 Flanged Bearing |
| SH12S-0.2 | Spring Shim 0.2mm |
| SH12F0.5 | Front Axle Spacer 0.5mm |
| SH12R0.5 | Rear Axle Spacer 0.5mm |
| SH1.5W | 7.4x3x1.5mm Spacer |
| SH12R2.0 | Rear Axle Spacer 2.0mm |
| SH12R3.5 | Rear Axle Spacer 3.5mm |
| SH0.1 | 6x8x0.1mm Shim |
| SH0.25 | 6x3x0.25mm Spacer |
| SH0.5 | 6x3x0.5mm Spacer (Silver) |
| SH1.0 | 6x3x1.0mm Spacer (Gray) |
| SH5.5X7.7X0.05 | 5.5x7.7X0.05 5.5x7.7x0.05mm Shim |
| OR155SI | 1.5x5mm O-Ring Silicone |
| OR230 | 2x30mm O-Ring |
| OR14V | 1x4mm O-Ring Viton |
| OR15 | 1x5mm O-Ring |
| OR91 | 9x1mm O-Ring |
| OR915 | 9x1.5mm O-Ring |
| SC25X8 | M2.5x8 Cap Head Screw |
| SC3X5 | M3x5 Cap Head Screw |
| SC3X6 | M3x6 Cap Head Screw |
| SB3X5 | M3x5 Button Head Screw |
| SB3X6 | M3x6 Button Head Screw |
| SB3X8 | M3x8 Button Head Screw |
| SB3X10 | M3x10 Button Head Screw |
| SB3X12 | M3x12 Button Head Screw |
| SF3X10 | M3x10 Flat Head Screw |
| SB3X5AL | M3x5 Alloy Screw |
| ST112 | Centering Screw |
| STS-A12 | A12 Stickers Sheet |
| SIO100K | 100k Silicone Oil |
| STA1212-X | Composite Axle |
| DG1XM | DG1XM Gauge |
| T03 | 6/7 mm Wrench |
| AK1.5 | 1.5 mm Allen Key |
| RHG 4.2X | Ride Height Gauge |
| CS-1 | Carbon Spool Set |
| AT1204-ZTL | Steering Block Zero Trail |
| ST1208-C5AL | Steering Hub Post 5 Deg |
| ST1208-C6AL | Steering Hub Post 6 Deg |
| ST1208-C2AL | Steering Hub Post 2 Deg |
| ST1208-C6 | Steering Hub Post 6 Deg |
| ST1216 | Balance Weight 5 g |
| ST1212 | Spring Steel Axle |
| C1206 | Carbon Axle |
| OR155PU | 1.5x3mm O-Ring PU |
| SH12R5.5 | Rear Axle Spacer 5.5mm |
| SC25X7AL | 2.5x7 Cap Head Screw Alloy Right Hub |
| SPR12F-C1.7 | Front Spring C1.7 |
| SPR12F-C1.3 | Front Spring C1.3 |
| SPR12F-C0.9 | Front Spring C0.9 |
| SPR12F-C0.7 | Front Spring C0.7 |
| C1205-6.0 | Suspension Plate |
| C1201-6.0 | Servo Plate |
| C1201 | Servo Plate |
| C1205-ZT | Suspension Plate Zero Trail |
| C1205-X-1.5 | Suspension Plate |
| C1201-ZT | Servo Plate Zero Trail |
| AM1204WC | Chassis Plate |
| ST1208-C2ST | Steering Hub Post 2 Deg |
| ST1208-C4ST | Steering Hub Post 2Deg |
| ST1208-C5ST | Steering Hub Post 5 Deg |
| ST1208-C6ST | Steering Hub Post 6 Deg |
| SPR12S-C0.4 | Side Spring Long C0.4 |
| SPR12S-C0.5 | Side Spring Long C0.5 |
| SPR12S-C0.6 | Side Spring Long C0.6 |
| ELRC | Extra Low Roll Center Set |
| HRC | High Roll Center Set |
| EHRC | Extra High Roll Center Set |
| SH12F0.1 | Front Axle Spacer 0.1mm |
