Part number | Part name |
---|---|
5116 | Ball bearings, blue rubber sealed (5x11x4mm) (2) |
5114 | Ball bearings, blue rubber shield (5x8x2.5mm) (2) |
2545 | Bushings (plastic) (5x8x2.5mm) (4) |
1985 | PTFE-coated Washers, 5x8x0.5mm (20) (use with ball bearings) |
1926 | Antenna caps, vinyl (2)/ antenna spool |
1726 | Antenna, tube (1)/ vinyl antenna cap (1)/ wire retainer (1) |
1834 | Body Clips (12) (standard size) |
1815 | Body washers (8) |
6716 | Body Washers, Foam, 2mm/3mm/4mm |
2417 | Body, Bandit (front & rear) (clear, requires painting)/ window, lights, grille decal sheet |
2433 | Body, Bandit, pink (painted, decals applied) |
2450 | Body, Bandit (also fits Bandit VXL), black & red/ wing (painted, decals applied) |
2450X | Body, Bandit (also fits Bandit VXL), green/ wing (painted, decals applied) |
2450T | Body, Bandit (also fits Bandit VXL), orange/ wing (painted, decals applied) |
2436X | Body, Bandit VXL, blue/ wing (painted, decals applied) |
2436L | Body, Bandit VXL, ProGraphix wing (graphics are printed, requires paint & final color application)/ decal sheet |
2436T | Body, Bandit VXL, purple/ wing (painted, decals applied) |
2450L | Body, Bandit, ProGraphix wing (graphics are printed, requires paint & final color application)/ decal sheet |
2514 | Decal sheet, racing sponsors |
5185 | Tires, rubber (2) (fits Traxxas wheelie bar wheels) |
4974 | Wheelie Bar arm (1)/ connector (1)/ 3x12 SS (hex drive) (4) |
3677X | Wheelie bar mount (1)/ hardware (blue) |
3677A | Wheelie bar mount (1)/ hardware (green) |
3677P | Wheelie bar mount (1)/ hardware (pink) |
3677 | Wheelie bar mount (1)/ hardware (Stampede, Rustler, Bandit series) |
3678 | Wheelie bar, assembled (black) (fits Slash, Stampede, Rustler, Bandit series) |
3678X | Wheelie bar, assembled (blue) (fits Stampede, Rustler, Bandit series) |
3678A | Wheelie bar, assembled (green) (fits Slash, Stampede, Rustler, Bandit series) |
3678T | Wheelie bar, assembled (orange) (fits Slash, Stampede, Rustler, Bandit series) |
3678P | Wheelie bar, assembled (pink) (fits Slash, Stampede, Rustler, Bandit series) |
3678R | Wheelie bar, assembled (red) (fits Slash, Stampede, Rustler, Bandit series) |
4976 | Wheels (4)/ Axles (2), for Maxx Wheelie Bar |
5186A | Wheels, aluminum (blue-anodized) (2)/ 5x8mm ball bearings (4)/ axles (2)/ rubber tires (2) |
5186 | Wheels, aluminum (red-anodized) (2)/ 5x8mm ball bearings (4)/ axles (2)/ rubber tires (2) |
2615 | Wing buttons (2)/ set screws (2)/ spacers (2)/ 3x8mm CS (2) |
2414 | Wing wire |
9463X | Axle, wheelie bar, 6061-T6 aluminum (blue-anodized) (1)/ 3x12 BCS (with threadlock) (2) |
9463 | Axle, wheelie bar, 6061-T6 aluminum (gray-anodized) (1)/ 3x12 BCS (with threadlock) (2) |
9463G | Axle, wheelie bar, 6061-T6 aluminum (green-anodized) (1)/ 3x12 BCS (with threadlock) (2) |
9463A | Axle, wheelie bar, 6061-T6 aluminum (orange-anodized) (1)/ 3x12 BCS (with threadlock) (2) |
9463R | Axle, wheelie bar, 6061-T6 aluminum (red-anodized) (1)/ 3x12 BCS (with threadlock) (2) |
3727 | Battery hold-down plate (black)/ metal posts (2)/body clips (2) |
3727A | Battery hold-down plate (grey)/ metal posts (2)/ body clips (2) |
3628 | Box, receiver (sealed)/ foam pad/2.5x8mm CS (4)/ 3x10mm CS (2) |
2735 | Bumper (front) |
2735P | Bumper (front) (pink) |
3735 | Bumper, front/ 4x12 CCS (2) (fits 2WD Rustler or Bandit) (for LED light kit installation) |
3728 | Lower chassis (black) (166mm long battery compartment) (fits both flat and hump style battery packs) |
3722X | Lower chassis (black) (166mm long battery compartment) (fits both flat and hump style battery packs)(use only with #3725R ESC mounting plate) |
3728A | Lower chassis (gray) (166mm long battery compartment) (fits both flat and hump style battery packs) |
3722R | Lower chassis (grey) (166mm long battery compartment) (fits both flat and hump style battery packs) (use only with #3725R ESC mounting plate) |
3725R | Mounting plate, electronic speed control (for installation of XL-5/VXL into Bandit or Rustler) |
3629 | Seal kit, receiver box (includes o-ring, seals, and silicone grease) |
9462X | Side plates, wheelie bar, blue (aluminum) (2) |
9462 | Side plates, wheelie bar, charcoal gray (aluminum) (2) |
9462G | Side plates, wheelie bar, green (aluminum) (2) |
9462A | Side plates, wheelie bar, orange (aluminum) (2) |
9462P | Side plates, wheelie bar, pink (aluminum) (2) |
9462R | Side plates, wheelie bar, red (aluminum) (2) |
5185 | Tires, rubber (2) (fits Traxxas wheelie bar wheels) |
3723 | Upper chassis (black) |
3729 | Upper chassis (black) |
3729A | Upper chassis (gray) |
3723A | Upper chassis (grey) |
4974 | Wheelie Bar arm (1)/ connector (1)/ 3x12 SS (hex drive) (4) |
3677X | Wheelie bar mount (1)/ hardware (blue) |
3677A | Wheelie bar mount (1)/ hardware (green) |
3677P | Wheelie bar mount (1)/ hardware (pink) |
3677 | Wheelie bar mount (1)/ hardware (Stampede, Rustler, Bandit series) |
9464 | Wheelie bar mount (heavy duty) |
2477 | Wheelie bar mount/ 3x40 BCS (1)/ 3x30 BCS (1)/ 3x12 BCS (1) (for LED light kit installation) |
3678 | Wheelie bar, assembled (black) (fits Slash, Stampede, Rustler, Bandit series) |
3678X | Wheelie bar, assembled (blue) (fits Stampede, Rustler, Bandit series) |
3678A | Wheelie bar, assembled (green) (fits Slash, Stampede, Rustler, Bandit series) |
3678T | Wheelie bar, assembled (orange) (fits Slash, Stampede, Rustler, Bandit series) |
3678P | Wheelie bar, assembled (pink) (fits Slash, Stampede, Rustler, Bandit series) |
3678R | Wheelie bar, assembled (red) (fits Slash, Stampede, Rustler, Bandit series) |
9460 | Wheelie bar, black (assembled)/ wheelie bar mount |
9460X | Wheelie bar, black chrome (assembled)/ wheelie bar mount |
4976 | Wheels (4)/ Axles (2), for Maxx Wheelie Bar |
5186A | Wheels, aluminum (blue-anodized) (2)/ 5x8mm ball bearings (4)/ axles (2)/ rubber tires (2) |
5186 | Wheels, aluminum (red-anodized) (2)/ 5x8mm ball bearings (4)/ axles (2)/ rubber tires (2) |
9461X | Wheels, wheelie bar, 6061-T6 aluminum (blue-anodized) (2)/ 5x8x2.5mm ball bearings (4)/ o-rings (2)/ 5x8x0.3mm TW (2) |
9461T | Wheels, wheelie bar, 6061-T6 aluminum (gray-anodized) (2)/ 5x8x2.5mm ball bearings (4)/ o-rings (2)/ 5x8x0.3mm TW (2) |
9461G | Wheels, wheelie bar, 6061-T6 aluminum (green-anodized) (2)/ 5x8x2.5mm ball bearings (4)/ o-rings (2)/ 5x8x0.3mm TW (2) |
9461A | Wheels, wheelie bar, 6061-T6 aluminum (orange-anodized) (2)/ 5x8x2.5mm ball bearings (4)/ o-rings (2)/ 5x8x0.3mm TW (2) |
9461P | Wheels, wheelie bar, 6061-T6 aluminum (pink-anodized) (2)/ 5x8x2.5mm ball bearings (4)/ o-rings (2)/ 5x8x0.3mm TW (2) |
9461R | Wheels, wheelie bar, 6061-T6 aluminum (blue-anodized) (4)/ o-rings (2)/ 5x8x0.3mm TW (2) |
9461R | Wheels, wheelie bar, 6061-T6 aluminum (red-anodized) (2)/ 5x8x2.5mm ball bearings (4)/ o-rings (2)/ 5x8x0.3mm TW (2) |
9461 | Wheels, wheelie bar, black (26mm (2), 18mm (2)) |
2380 | Differential, complete (fits 1/10-scale 2WD Rustler, Bandit, Stampede, Slash) |
2381X | Main diff with steel ring gear/ side cover plate/ screws (Bandit, Stampede, Rustler) |
2382 | Planet gears (4)/ planet shafts (4)/ sun gears (2)/ sun gear alignment shaft (1) all hardened steel |
2388X | Planetary gear differential with steel ring gear (complete) (fits Bandit, Stampede, Rustler) |
1647 | Silicone Grease |
