| Part number | Part name |
|---|---|
| 5119 | Ball bearings, blue rubber sealed (10x15x4mm) (2) |
| 5120 | Ball bearings, blue rubber sealed (12x18x4mm) (2) |
| 5116 | Ball bearings, blue rubber sealed (5x11x4mm) (2) |
| 5114 | Ball bearings, blue rubber sealed (5x8x2.5mm) (2) |
| 5105 | Ball bearings, blue rubber sealed (6x10x3mm) (2) |
| 5118 | Ball bearings, blue rubber sealed (8x16x5mm) (2) |
| 8319 | Body bumper, foam |
| 1834A | Body clips, black (12) (standard size) |
| 8315 | Body mounts, front & rear (2) |
| 8316 | Body mounts, front & rear/ body mount posts/ body mount sliders |
| 8317 | Body washers, foam |
| 8391 | Body, Cadillac CTS-V (clear, requires painting)/ decal sheet (includes side mirrors, spoiler, & mounting hardware) |
| 8391A | Body, Cadillac CTS-V, blue (painted, decals applied) |
| 8391X | Body, Cadillac CTS-V, silver (painted, decals applied) |
| 8386 | Body, Chevrolet Corvette Z06 (clear, requires painting)/ decal sheet (includes side mirrors, spoiler, & mounting hardware) |
| 8386X | Body, Chevrolet Corvette Z06, blue (painted, decals applied) |
| 8386A | Body, Chevrolet Corvette Z06, graphite (painted, decals applied) |
| 8386R | Body, Chevrolet Corvette Z06, red (painted, decals applied) |
| 8311 | Body, Ford GT® (clear, requires painting)/ decal sheet (includes tail lights, exhaust tips, & mounting hardware) |
| 8311X | Body, Ford GT®, black (painted, decals applied) (tail lights, exhaust tips, & mounting hardware (part #8314) sold separately) |
| 8311A | Body, Ford GT®, blue (painted, decals applied) (tail lights, exhaust tips, & mounting hardware (part #8314) sold separately) |
| 8311R | Body, Ford GT®, red (painted, decals applied) (tail lights, exhaust tips, & mounting hardware (part #8314) sold separately) |
| 8312 | Body, Ford Mustang (clear, requires painting)/ window masks/ decal sheet |
| 8312X | Body, Ford Mustang, black (painted, decals applied) |
| 8312A | Body, Ford Mustang, Grabber Blue (painted, decals applied) |
| 8312T | Body, Ford Mustang, orange (painted, decals applied) |
| 8336 | Bumper, rear (1)/ rear body mount (1) |
| 8393 | Decal sheet, Cadillac CTS-V |
| 8387 | Decal sheets, Chevrolet Corvette Z06 |
| 8392 | Mirrors, side, black (left & right)/ mirror retainers (2)/ body clips (4)/ o-rings (4)/ spoiler, black/ spoiler retainer (1)/ 1.6x5 BCS (self-tapping) (3) (fits #8391 body) |
| 8388 | Mirrors, side, black (left & right)/ mirror retainers (2)/ spoiler, black/ spoiler retainer (1)/ 1.6x5 BCS (self-tapping) (3)/ 2.6x8 BCS (self-tapping) (2) (fits #8386 body) |
| 8314 | Tail lights (2)/ tail light mounts (4)/ exhaust tips (2)/ exhaust tip mount (1)/ 3x10 flat-head screws (2)/ 3x8 BCS (2) |
| 8367 | Brake calipers (red), front (2)/ rear (2) |
| 8356 | Wheel hubs, hex (disc brake rotors) (4) |
| 8381 | Housing, differential (front) |
| 8380 | Housing, differential (rear) |
| 8327 | Battery hold-down/ battery clip/ hold-down post/ screw pin/ pivot post screw (for 256mm wheelbase) |
| 8319 | Body bumper, foam |
| 8324 | Box, receiver (sealed) (steering servo mount)/ receiver cover/ access plug/ foam pads/ silicone grease/ 2.5x10 CS (3) |
| 8335 | Bumper, front (1 each, upper & lower) |
| 8336 | Bumper, rear (1)/ rear body mount (1) |
| 8322 | Chassis |
| 8321 | Chassis brace (front) |
| 8323 | Gear cover (rear chassis brace)/ wire retainer |
| 5381 | Carrier, differential/ ring gaskets (2)/ ring gear gasket/ 6x10x0.5 TW |
| 5136X | Differential oil kit (50cc of 1 each: 10K, 30K, 50K weights) |
| 8381 | Housing, differential (front) |
| 8380 | Housing, differential (rear) |
| 8379 | Housing, spool / spool shaft/ bushing |
| 6879R | Ring gear, differential/ pinion gear, differential (machined, spiral cut) (rear) |
| 6879 | Ring gear, differential/ pinion gear, differential (rear) |
| 8353X | Drive cups, inner (2) (steel constant-velocity driveshafts)/ screw pins (2) |
| 8353 | Drive cups, inner (2)/ screw pins (2) |
| 8355X | Driveshaft, center, aluminum (blue-anodized) |
| 8355G | Driveshaft, center, aluminum (green-anodized) |
| 8355R | Driveshaft, center, aluminum (red-anodized) |
| 8355 | Driveshaft, center, aluminum/ pin |
| 8350 | Driveshaft, front (2) |
| 8351 | Driveshaft, rear (2) |
| 8350X | Driveshafts, steel constant-velocity (assembled), front (2) |
| 8351X | Driveshafts, steel constant-velocity (assembled), rear (2) |
| 8382 | O-rings (12) |
| 2754 | Stub axle pins (4) |
| 8354 | Stub axles (front or rear) (2) |
| 8356 | Wheel hubs, hex (disc brake rotors) (4) |
| 8330 | Bulkhead, front |
| 8341 | Camber link/toe link set (plastic/ non-adjustable) (front & rear) |
| 8332 | Caster blocks (c-hubs) (2)/ kingpin bushings (4) |
| 8334 | Mounts, suspension arms (front & rear)/ hinge pin retainers (4) |
| 8334X | Mounts, suspension arms, aluminum (blue-anodized) (front & rear)/ hinge pin retainers (12)/ inserts (6) |
| 8334G | Mounts, suspension arms, aluminum (green-anodized) (front & rear)/ hinge pin retainers (12)/ inserts (6) |
| 8334R | Mounts, suspension arms, aluminum (red-anodized) (front & rear)/ hinge pin retainers (12)/ inserts (6) |
| 1985 | PTFE-coated washers, 5x8x0.5mm (20) (use with ball bearings) |
| 8345 | Servo saver nuts, aluminum, blue-anodized (hex (1), serrated (1)) |
| 8345G | Servo saver nuts, aluminum, green-anodized (hex (1), serrated (1)) |
| 8345R | Servo saver nuts, aluminum, red-anodized (hex (1), serrated (1)) |
| 8344 | Servo saver/ servo saver spring/ servo horn, steering |
| 8344 | Servo saver/ servo saver spring/ servo horn, steering |
| 2075R | Servo, digital high-speed, metal gear (ball bearing), waterproof |
| 2075 | Servo, digital high-torque (ball bearing), waterproof |
| 2075X | Servo, digital high-torque, metal gear (ball bearing), waterproof |
| 3350R | Velineon® VXL-3s Brushless Power System, waterproof (includes VXL-3s waterproof ESC, Velineon 3500 motor, and speed control mounting plate (part #3725R)) |
| 3355R | Velineon® VXL-3s Electronic Speed Control, waterproof (brushless) (fwd/rev/brake) |
| 3018R | XL-5 Electronic Speed Control, waterproof (land version, low-voltage detection, fwd/rev/brake) |
| 2842X | 5000mAh 7.4v 2-Cell 25C LiPo Battery |
| 2843X | 5800mAh 7.4v 2-Cell 25C LiPo Battery |
| 2869X | 7600mAh 7.4v 2-Cell 25C LiPo Battery |
| 2976 | AC to DC converter, 40W |
| 2938X | Adapter, Traxxas® iD® LiPo battery (adapts Traxxas iD batteries to separate balance ports) |
| 2943 | Battery charge indicators (green (4), blue (4), gray (4)) |
| 6548 | Battery door, transmitter (replacement for #6516, 6517, 6528, 6529, 6530 transmitters) |
| 2914X | Battery, Power Cell AA Alkaline (4) |
| 2923X | Battery, Power Cell, 3000mAh (NiMH, 7-C flat, 8.4V) |
| 2940X | Battery, Series 3 Power Cell, 3300mAh (NiMH, 7-C flat, 8.4V) |
| 2950X | Battery, Series 4 Power Cell, 4200mAh (NiMH, 7-C flat, 8.4V) |
| 2960X | Battery, Series 5 Power Cell, 5000mAh (NiMH, 7-C flat, 8.4V) |
| 2983 | Battery/charger completer pack (includes #2969 2-amp NiMH peak detecting AC charger (1), #2923X 3000mAh 8.4V 7-cell NiMH battery (1)) |
| 2992 | Battery/charger completer pack (includes #2970 iD® charger (1), #2843X 5800mAh 7.4V 2-cell 25C LiPo battery (1)) |
| 2260 | BEC assembly (complete) |
| 2975 | Charger, DC, 4 amp (6 - 7 cell, 7.2 - 8.4 volt, NiMH) |
| 2972 | Charger, EZ-Peak® Dual, 100W, NiMH/LiPo with iD® Auto Battery Identification |
| 2973 | Charger, EZ-Peak® Live Dual, 200W, NiMH/LiPo with iD® Auto Battery Identification |
| 2971 | Charger, EZ-Peak® Live, 100W, NiMH/LiPo with iD® Auto Battery Identification |
| 2981 | Charger, EZ-Peak® Plus 4s, 8 amp, NiMH/LiPo with iD® Auto Battery Identification |
| 2970 | Charger, EZ-Peak® Plus, 4 amp, NiMH/LiPo with iD® Auto Battery Identification |
| 6525 | Communication link, telemetry expander |
| 6512 | Cover plate, Traxxas Link™ Wireless Module |
| 2978 | Fuse, charger, 5A (2) (for #2974, 2975, 2977) |
| 2072A | Gear set (for 2070, 2075 servos) |
| 2968X | LiPo cell voltage checker/balancer (includes #2938X adapter for Traxxas® iD® batteries) |
| 2968 | LiPo cell voltage checker/balancer (requires #2938X adapter for Traxxas® iD® batteries) |
| 6560 | Mount, telemetry expander (fits 4-Tec® 2.0 & 3.0) |
| 6535 | Mount, temperature sensor (electric motors)/ wire tie/ thermal pad |
| 6519 | Receiver, micro, TQ 2.4GHz (3-channel) |
| 6533 | Receiver, micro, TQi 2.4GHz with telemetry & TSM (5-channel) |
| 6552 | Seal kit, expander box (includes o-ring, seals, and silicone grease) |
| 6526 | Sensor, auto-detectable, temperature |
| 6527 | Sensor, auto-detectable, voltage |
| 6521 | Sensor, temperature and voltage (long) |
| 8345 | Servo saver nuts, aluminum, blue-anodized (hex (1), serrated (1)) |
| 8345G | Servo saver nuts, aluminum, green-anodized (hex (1), serrated (1)) |
| 8345R | Servo saver nuts, aluminum, red-anodized (hex (1), serrated (1)) |
| 8344 | Servo saver/ servo saver spring/ servo horn, steering |
| 2075R | Servo, digital high-speed, metal gear (ball bearing), waterproof |
| 2075 | Servo, digital high-torque (ball bearing), waterproof |
| 2075X | Servo, digital high-torque, metal gear (ball bearing), waterproof |
| 8369 | Tires, Response 1.9" Touring (front) (2)/ foam inserts (2) |
| 8371 | Wheels, 1.9" split-spoke (black chrome) (front) (2) |
| 8372 | Wheels, 1.9" split-spoke (black chrome) (wide, rear) (2) |
| 7374A | Wheels, Volk Racing TE37 (green) (2) |
| 3433X | Body reamer (aluminum handle) |
| 3433 | Body reamer (plastic handle) |
| 3436 | Cap, body reamer |
| 3432 | Scissors, curved tip |
| 3431 | Scissors, straight tip |
| 8712 | Speed Bit Essentials Set, hex and nut driver, 7-piece, includes premium handle (medium), travel pouch, hex drivers (straight: 1.5mm, 2.0mm, 2.5mm) and nut drivers (5.0mm, 5.5mm, 7.0mm, and 8.0mm), 1/4" drive |
| 8721 | Speed bit handle, medium (one piece) |
| 8720 | Speed bit handle, premium, large (rubber overmold) |
| 8722 | Speed bit handle, premium, medium (rubber overmold) |
| 8710 | Speed Bit Master Set, hex and nut driver, 13-piece, includes premium handle (medium), travel pouch, hex drivers (straight: 1.5mm, 2.0mm, 2.5mm, 3.0mm), (ball-end: 2.0mm, 2.5mm, 3.0mm), and nut drivers (4.00mm, 4.50mm, 5.00mm, 5.50mm, 7.00mm, 8.00mm) |
| 8711 | Speed Bit Master Set, hex driver, 7-piece straight and ball end, includes premium handle (medium), travel pouch, hex drivers (straight: 1.5mm, 2.0mm, 2.5mm, 3.0mm) (ball end: 2.0mm, 2.5mm, 3.0mm), 1/4" drive |
| 8719 | Speed Bit Master Set, nut driver, 6-piece, includes premium handle (medium), travel pouch, and nut drivers (4.0mm, 4.5mm, 5.0mm, 5.5mm, 7.0mm, 8.0mm), 1/4" drive |
| 8716 | Speed Bit Set, hex driver, 2-piece ball-end (2.0mm, 2.5mm), 1/4" drive |
| 8716X | Speed Bit Set, hex driver, 3-piece ball-end (2.0mm, 2.5mm, 3.0mm), 1/4" drive |
| 8715 | Speed Bit Set, hex driver, 3-piece straight (1.5mm, 2.0mm, 2.5mm), 1/4" drive |
| 8715X | Speed Bit Set, hex driver, 4-piece straight (1.5mm, 2.0mm, 2.5mm, 3.0mm), 1/4" drive |
| 2748R | Tool set (includes 1.5mm hex wrench / 2.0mm hex wrench / 2.5mm hex wrench/ 4-way wrench/ 8mm & 4mm wrench/ U-joint wrench) |
| 3415 | Tool set with pouch (includes 1.5mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm, 4mm drivers/ 4mm, 5mm, 5.5mm, 7mm and 8mm nut drivers/ 2mm, 4mm, and 5mm slotted screwdrivers/ #00 Phillips, #0 Phillips, and #1 Phillips screwdrivers/ 4mm and 8mm wrench/ driver handle |
| 8341 | Camber link/toe link set (plastic/ non-adjustable) (front & rear) |
| 8342 | Toe links, steel (34mm) (2) |
| 8341X | Turnbuckles, aluminum (blue-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
| 8341G | Turnbuckles, aluminum (green-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
| 8341R | Turnbuckles, aluminum (red-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
| 2514 | Decal sheet, racing sponsors |
| 9950 | Official Team Traxxas® racing decal set (flag logo/ 6-color) |
| 9909 | Traxxas® racing banner, red & black (3x7 feet) |
| 8375 | Tires & wheels, assembled, glued (split-spoke black chrome wheels, 1.9" Response tires, foam inserts) (front (2), rear (extra wide) (2)) (VXL rated) |
| 8378 | Tires and wheels, assembled, glued (split-spoke black chrome wheels, 1.9" Drift tires) (front and rear) |
| 8373 | Tires and wheels, assembled, glued (split-spoke black chrome wheels, 1.9" Response tires) (front) (2) |
| 8374 | Tires and wheels, assembled, glued (split-spoke black chrome wheels, 1.9" Response tires) (extra wide, rear) (2) |
| 8376G | Tires and wheels, assembled, glued (split-spoke green wheels, 1.9" Drift tires) (front) |
| 8377G | Tires and wheels, assembled, glued (split-spoke green wheels, 1.9" Drift tires) (rear) |
| 8374G | Tires and wheels, assembled, glued (split-spoke green wheels, 1.9" Response tires) (extra wide, rear) (2) (VXL rated) |
| 8373G | Tires and wheels, assembled, glued (split-spoke green wheels, 1.9" Response tires) (front) (2) (VXL rated) |
| 8376A | Tires and wheels, assembled, glued (split-spoke orange wheels, 1.9" Drift tires) (front) |
| 8377A | Tires and wheels, assembled, glued (split-spoke orange wheels, 1.9" Drift tires) (rear) |
| 8374A | Tires and wheels, assembled, glued (split-spoke orange wheels, 1.9" Drift tires) (extra wide, rear) (2) (VXL rated) |
| 8373A | Tires and wheels, assembled, glued (split-spoke orange wheels, 1.9" Response tires) (front) (2) (VXL rated) |
| 8370 | Tires, Response 1.9" Touring (extra wide, rear)/ foam inserts (2) (fits #8372 wide wheel) |
| 2362 | Rebuild kit, Ultra shocks (for 2 shocks) |
| 1942 | Rod ends (16 long & 4 short)/ hollow ball connectors (18)/ ball screws (2) |
| 2742X | Rod ends, short (6)/ hollow balls (6) |
| 8361 | Shock caps (black) (4) (assembled with hollow balls) |
| 8362X | Spring, shock (blue) (3.7 rate) (2) |
| 8362G | Spring, shock (green) (3.7 rate) (2) |
| 8362P | Spring, shock (pink) (3.7 rate) (2) |
| 8366 | Spring, shock (red) (2.8 rate, white stripe) (2) |
| 8365 | Spring, shock (red) (3.325 rate, orange stripe) (2) |
| 8362 | Spring, shock (red) (3.7 rate) (2) |
| 8363 | Spring, shock (red) (4.075 rate, green stripe) (2) |
| 8364 | Spring, shock (red) (4.4 rate, black stripe) (2) |
| 8360 | Ultra Shocks (gray) (short) (includes spring pre-load spacers) (2) |
| 2728 | Ball bearings (5x8x2.5mm) (2) |
| 8323 | Gear cover (rear chassis brace)/ wire retainer |
| 2419 | Gear, 19-T pinion (48-pitch) / set screw |
| 2421 | Gear, 21-T pinion (48-pitch) / set screw |
| 2422 | Gear, 22-T pinion (48-pitch) (fits 3mm shaft)/ set screw |
| 2423 | Gear, 23-T pinion (48-pitch) (fits 3mm shaft)/ set screw |
| 2424 | Gear, 24-T pinion (48-pitch) (fits 3mm shaft)/ set screw |
| 2426 | Gear, 26-T pinion (48-pitch) (fits 3mm shaft)/ set screw |
| 4725 | Gear, pinion (25-tooth) (48-pitch) / set screw |
| 4728 | Gear, pinion (28-tooth) (48-pitch) (fits 3mm shaft)/ set screw |
| 8359 | Spur gear, 62-tooth |
| 8357 | Spur gear, 70-tooth |
| 8345 | Servo saver nuts, aluminum, blue-anodized (hex (1), serrated (1)) |
| 8345G | Servo saver nuts, aluminum, green-anodized (hex (1), serrated (1)) |
| 8345R | Servo saver nuts, aluminum, red-anodized (hex (1), serrated (1)) |
| 8344 | Servo saver/ servo saver spring/ servo horn, steering |
| 8342 | Toe links, steel (34mm) (2) |
| 8341 | Camber link/toe link set (plastic/ non-adjustable) (front & rear) |
| 8341X | Turnbuckles, aluminum (blue-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
| 8341G | Turnbuckles, aluminum (green-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
| 8341R | Turnbuckles, aluminum (red-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
