Part number | Part name |
---|---|
5119 | Ball bearings, blue rubber sealed (10x15x4mm) (2) |
5120 | Ball bearings, blue rubber sealed (12x18x4mm) (2) |
5116 | Ball bearings, blue rubber sealed (5x11x4mm) (2) |
5114 | Ball bearings, blue rubber sealed (5x8x2.5mm) (2) |
5105 | Ball bearings, blue rubber sealed (6x10x3mm) (2) |
5118 | Ball bearings, blue rubber sealed (8x16x5mm) (2) |
9311 | Body, Chevrolet Corvette Stingray (clear, trimmed, requires painting)/ decal sheet (includes side mirrors, spoiler, grilles, vents, hardware, & clipless mounting) |
9311A | Body, Chevrolet Corvette Stingray, complete (black) (painted, decals applied) (includes side mirrors, spoiler, grilles, vents, & clipless mounting) |
9311X | Body, Chevrolet Corvette Stingray, complete (blue) (painted, decals applied) (includes side mirrors, spoiler, grilles, vents, & clipless mounting) |
9311R | Body, Chevrolet Corvette Stingray, complete (red) (painted, decals applied) (includes side mirrors, spoiler, grilles, vents, & clipless mounting) |
9311T | Body, Chevrolet Corvette Stingray, complete (silver) (painted, decals applied) (includes side mirrors, spoiler, grilles, vents, & clipless mounting) |
9318 | Exhaust tips (2)/ exhaust tip mounts (2)/ 2.6X8 BCS (4) |
9316 | Grille, Chevrolet Corvette Stingray/ grille mount (3)/ headlight housing (2)/ lens (2)/ headlight mount (2)/ 2.6x6mm BCS (4)/ 2.6x8mm BCS (8) |
9313 | Latch, body mount, front (for clipless body mounting) (attaches to #9311 body) |
9315 | Latch, body mount, rear (with engine bay) (for clipless body mounting) (attaches to #9311 body) |
9317 | Mirrors, side (left & right)/ mounts (left & right)/ trim, side (left & right)/ trim mounts (left & right)/ 2.6x8mm BCS (2)/ 1.6x7mm BCS (8) |
9321 | Rear window/ rear window retainer/ engine cover/ 2.6x8mm BCS (8) |
9319 | Tail lights (2)/ tail light mounts (2)/ wing/ wing mount/ vent, rear (2)/ vent mount, rear (2)/ 2.6x8mm BCS (2)/ 1.6x7mm BCS (6) |
8367 | Brake calipers (red), front (2)/ rear (2) |
8356 | Wheel hubs, hex (disc brake rotors) (4) |
8381 | Housing, differential (front) |
8380 | Housing, differential (rear) |
8326 | Battery hold-down/ battery clip/ hold-down post/ foam spacer/ screw pin (for 288mm wheelbase) |
9314 | Body mount, rear (for clipless body mounting) |
8324 | Box, receiver (sealed) (steering servo mount)/ receiver cover/ access plug/ foam pads/ silicone grease/ 2.5x10 CS (3) |
9320 | Bumper, front/ bumper mount/ splitter/ bumper foam |
8325 | Chassis (for 288mm wheelbase) |
8321 | Chassis brace (front) |
8323 | Gear cover (rear chassis brace)/ wire retainer |
5381 | Carrier, differential/ x-ring gaskets (2)/ ring gear gasket/ 6x10x0.5 TW |
5136X | Differential oil kit (50cc of 1 each: 10K, 30K, 50K weights) |
8381 | Housing, differential (front) |
8380 | Housing, differential (rear) |
8379 | Housing, spool/ spool shaft/ bushing |
6879R | Ring gear, differential/ pinion gear, differential (machined, spiral cut) (rear) |
6879 | Ring gear, differential/ pinion gear, differential (rear) |
8353X | Drive cups, inner (2) (steel constant-velocity driveshafts)/ screw pins (2) |
8353 | Drive cups, inner (2)/ screw pins (2) |
9355 | Driveshaft, center, steel (266mm)/ pin/ support, center driveshaft/ 5x11x4 bearing |
8350 | Driveshaft, front (2) |
8351 | Driveshaft, rear (2) |
8350X | Driveshafts, steel constant-velocity (assembled), front (2) |
8351X | Driveshafts, steel constant-velocity (assembled), rear (2) |
8382 | O-rings (12) |
2754 | Stub axle pins (4) |
8354 | Stub axles (front or rear) (2) |
8356 | Wheel hubs, hex (disc brake rotors) (4) |
8330 | Bulkhead, front |
8341 | Camber link/toe link set (plastic/ non-adjustable) (front & rear) |
8332 | Caster blocks (c-hubs) (2)/ kingpin bushings (4) |
8334 | Mounts, suspension arms (front & rear)/ hinge pin retainers (4) |
8334X | Mounts, suspension arms, aluminum (blue-anodized) (front & rear)/ hinge pin retainers (12)/ inserts (6) |
8334G | Mounts, suspension arms, aluminum (green-anodized) (front & rear)/ hinge pin retainers (12)/ inserts (6) |
8334R | Mounts, suspension arms, aluminum (red-anodized) (front & rear)/ hinge pin retainers (12)/ inserts (6) |
1985 | PTFE-coated washers, 5x8x0.5mm (20) (use with ball bearings) |
8345 | Servo saver nuts, aluminum, blue-anodized (hex (1), serrated (1)) |
8345G | Servo saver nuts, aluminum, green-anodized (hex (1), serrated (1)) |
8345R | Servo saver nuts, aluminum, red-anodized (hex (1), serrated (1)) |
8344 | Servo saver/ servo saver spring/ servo horn, steering |
8338 | Shock towers, front & rear |
8343 | Steering bellcranks/ hardware |
8337 | Steering block (2) |
2754 | Stub axle pins (4) |
8354 | Stub axles (front or rear) (2) |
8333 | Suspension arms, front (left & right) |
8340 | Suspension pin set, complete (front & rear) |
8398 | Sway bar kit, 4-Tec® 2.0 (front and rear) (includes front and rear sway bars and adjustable linkage) |
8342 | Toe links, steel (34mm) (2) |
8341X | Turnbuckles, aluminum (blue-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
8341G | Turnbuckles, aluminum (green-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
8341R | Turnbuckles, aluminum (red-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
8347 | Nuts, 4mm flanged nylon locking, serrated (black) (10) |
1985 | PTFE-coated washers, 5x8x0.5mm (20) (use with ball bearings) |
3229 | Screws, 2.5x10mm cap-head machine (hex drive) (6) |
3236 | Screws, 2.5x12mm cap-head machine (6) |
3215 | Screws, 2.5x6mm cap-head machine (hex drive) (6) |
2577 | Screws, 3x10mm button-head machine (hex drive) (6) |
2587 | Screws, 3x10mm cap-head machine (6) (no washer) |
2551 | Screws, 3x10mm countersunk machine (6) (hex drive) |
4859 | Screws, 3x10mm flat-head machine (hex drive) (4) |
2578 | Screws, 3x12mm button-head machine (hex drive) (6) |
2552 | Screws, 3x12mm countersunk machine (6) (hex drive) |
2593 | Screws, 3x14mm button-head machine (hex drive) (6) |
2579 | Screws, 3x15mm button-head machine (hex drive) (6) |
2553 | Screws, 3x15mm countersunk machine (6) (hex drive) |
8356 | Wheel hubs, hex (disc brake rotors) (4) |
9380 | LED light harness/ power harness/ zip ties (9) (fits #9311 body) |
2260 | BEC assembly (complete) |
2072A | Gear set (for 2070, 2075 servos) |
3785 | Motor, Titan® 12T (12-Turn, 550 size) |
8390 | Plate, motor |
2074 | Servo case/gaskets (for 2056 and 2075 waterproof servos) |
8345 | Servo saver nuts, aluminum, blue-anodized (hex (1), serrated (1)) |
8345G | Servo saver nuts, aluminum, green-anodized (hex (1), serrated (1)) |
8345R | Servo saver nuts, aluminum, red-anodized (hex (1), serrated (1)) |
8344 | Servo saver/ servo saver spring/ servo horn, steering |
2075R | Servo, digital high-speed, metal gear (ball bearing), waterproof |
2075 | Servo, digital high-torque (ball bearing), waterproof |
2075X | Servo, digital high-torque, metal gear (ball bearing), waterproof |
3350R | Velineon® VXL-3s Brushless Power System, waterproof (includes VXL-3s waterproof ESC, Velineon 3500 motor, and speed control mounting plate (part #3725R)) |
3355R | Velineon® VXL-3s Electronic Speed Control, waterproof (brushless) (fwd/rev/brake) |
3018R | XL-5 Electronic Speed Control, waterproof (land version, low-voltage detection, fwd/rev/brake) |
2842X | 5000mAh 7.4v 2-Cell 25C LiPo Battery |
2843X | 5800mAh 7.4v 2-Cell 25C LiPo Battery |
2869X | 7600mAh 7.4v 2-Cell 25C LiPo Battery |
2976 | AC to DC converter, 40W |
2938X | Adapter, Traxxas® iD® LiPo battery (adapts Traxxas iD batteries to separate balance ports) |
2943 | Battery charge indicators (green (4), blue (4), gray (4)) |
6548 | Battery door, transmitter (replacement for #6516, 6517, 6528, 6529, 6530 transmitters) |
2914 | Battery, Power Cell AA Alkaline (4) |
2923X | Battery, Power Cell, 3000mAh (NiMH, 7-C flat, 8.4V) |
2940X | Battery, Series 3 Power Cell, 3300mAh (NiMH, 7-C flat, 8.4V) |
2950X | Battery, Series 4 Power Cell, 4200mAh (NiMH, 7-C flat, 8.4V) |
2960X | Battery, Series 5 Power Cell, 5000mAh (NiMH, 7-C flat, 8.4V) |
2983 | Battery/charger completer pack (includes #2969 2-amp NiMH peak detecting AC charger (1), #2923X 3000mAh 8.4V 7-cell NiMH battery (1)) |
2992 | Battery/charger completer pack (includes #2970 iD® charger (1), #2843X 5800mAh 7.4V 2-cell 25C LiPo battery (1)) |
2260 | BEC assembly (complete) |
2969 | Charger, AC, 2 amp NiMH peak detecting (5-7 cell, 6.0-8.4 volt, NiMH only) |
2975 | Charger, DC, 4 amp (6 - 7 cell, 7.2 - 8.4 volt, NiMH) |
2972 | Charger, EZ-Peak® Dual, 100W, NiMH/LiPo with iD® Auto Battery Identification |
2973 | Charger, EZ-Peak® Live Dual, 200W, NiMH/LiPo with iD® Auto Battery Identification |
2971 | Charger, EZ-Peak® Live, 100W, NiMH/LiPo with iD® Auto Battery Identification |
2981 | Charger, EZ-Peak® Plus 4s, 8 amp, NiMH/LiPo with iD® Auto Battery Identification |
2970 | Charger, EZ-Peak® Plus, 4 amp, NiMH/LiPo with iD® Auto Battery Identification |
6525 | Communication link, telemetry expander |
6512 | Cover plate, Traxxas Link™ Wireless Module |
2978 | Fuse, charger, 5A (2) (for #2974, 2975, 2977) |
2072A | Gear set (for 2070, 2075 servos) |
2968X | LiPo cell voltage checker/balancer (includes #2938X adapter for Traxxas® iD® batteries) |
2968 | LiPo cell voltage checker/balancer (requires #2938X adapter for Traxxas® iD® batteries) |
6560 | Mount, telemetry expander (fits 4-Tec® 2.0 & 3.0) |
6535 | Mount, temperature sensor (electric motors)/ wire tie/ thermal pad |
6519 | Receiver, micro, TQ 2.4GHz (3-channel) |
6533 | Receiver, micro, TQi 2.4GHz with telemetry & TSM (5-channel) |
6552 | Seal kit, expander box (includes o-ring, seals, and silicone grease) |
6526 | Sensor, auto-detectable, temperature |
6527 | Sensor, auto-detectable, voltage |
6521 | Sensor, temperature and voltage (long) |
2074 | Servo case/gaskets (for 2056 and 2075 waterproof servos) |
8345 | Servo saver nuts, aluminum, blue-anodized (hex (1), serrated (1)) |
8345G | Servo saver nuts, aluminum, green-anodized (hex (1), serrated (1)) |
8345R | Servo saver nuts, aluminum, red-anodized (hex (1), serrated (1)) |
8344 | Servo saver/ servo saver spring/ servo horn, steering |
2075R | Servo, digital high-speed, metal gear (ball bearing), waterproof |
2075 | Servo, digital high-torque (ball bearing), waterproof |
2075X | Servo, digital high-torque, metal gear (ball bearing), waterproof |
6553X | Telemetry expander 2.0 and GPS module 2.0, TQi radio system |
6550X | Telemetry expander 2.0, TQi radio system (for use only with #6551X GPS module) |
6551X | Telemetry GPS module 2.0, TQi radio system (for use only with #6550X telemetry expander) |
6509R | TQi 2.4 GHz High Output radio system, 2-channel, Traxxas Link™ enabled, TSM (2-ch transmitter, 5-ch micro receiver) |
6507R | TQi 2.4 GHz High Output radio system, 4-channel with Traxxas Link™ Wireless Module, TSM (4-ch transmitter, 5-ch micro receiver) |
6516 | Transmitter, TQ 2.4GHz, 2-channel (transmitter only) |
8716 | Speed Bit Set, hex driver, 2-piece ball-end (2.0mm, 2.5mm), 1/4" drive |
8716X | Speed Bit Set, hex driver, 3-piece ball-end (2.0mm, 2.5mm, 3.0mm), 1/4" drive |
8715 | Speed Bit Set, hex driver, 3-piece straight (1.5mm, 2.0mm, 2.5mm), 1/4" drive |
8715X | Speed Bit Set, hex driver, 4-piece straight (1.5mm, 2.0mm, 2.5mm, 3.0mm), 1/4" drive |
2748R | Tool set (includes 1.5mm hex wrench / 2.0mm hex wrench / 2.5mm hex wrench/ 4-way wrench/ 8mm & 4mm wrench/ U-joint wrench) |
3415 | Tool set with pouch (includes 1.5mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm, 4mm drivers/ 4mm, 5mm, 5.5mm, 7mm and 8mm nut drivers/ 2mm, 4mm, and 5mm slotted screwdrivers/ #00 Phillips, #0 Phillips, and #1 Phillips screwdrivers/ 4mm and 8mm wrench/ driver handle |
8341 | Camber link/toe link set (plastic/ non-adjustable) (front & rear) |
8342 | Toe links, steel (34mm) (2) |
8341X | Turnbuckles, aluminum (blue-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
8341G | Turnbuckles, aluminum (green-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
8341R | Turnbuckles, aluminum (red-anodized), camber links, 32mm (front) (2)/ camber links, 28mm (rear) (2)/ toe links, 34mm (2)/ aluminum wrench |
