| Part number | Part name |
|---|---|
| A-17B | Brake Rod |
| A-34B | Stabilizer Ball End |
| A-41A | 6mm Ball |
| A-46 | Clutch Bell 14 Teeth / Bearing 5×10×4 |
| A-47A | Bearing 5×10×4 |
| A-53A | Throttle Spring |
| A-77G | Washer 4x10x0.15 |
| A-80A-BK | Brake Adjust Button(Black) |
| A-81 | Nylon Tie(S) |
| AS-03 | Inner Sponge For Tire |
| BT-120 | 1/8 SONIC Tires |
| E-37 | 6mm Ball & Socket |
| E-41A | Body Pin (S) |
| E-43 | Bearing 5×11×4 |
| G-19 | 4×46 Turnbuckle |
| G-25 | 7mm Ball |
| G-26 | 5×35 Turnbuckle |
| G-36 | Fiberglass Brake 31mm |
| J-03A | P-6 O-Ring |
| J-20 | Washer 13×16×0.2(Steel) |
| J-45-BK | Muffler Stay Post(Black) |
| J-47D | Shock Shaft Dust Covers(Black) |
| J-47F | M2.6 Nut |
| JS-14B | Bearing 6×10×3 |
| K-11A | Insert for Servo Saver |
| L-22 | Brake Lever |
| L-26 | 3×36 Turnbuckle |
| MK-18-BK | 9mm Muffler |
| PI-801B-P | 1/8 Manifold |
| PI-801C | 1/8 Spring |
| PI-801D | 1/8 Seal, Silicone |
| PI-813P | 1/8 EFRA-2080 PIPE |
| X1-26-BK | Alum. Wheel Hub, (Black) |
| X1-26A-BK | X1 Hex Nut (Black) |
| X1-27 | Knuckle Arm Bushing |
| X1-49 | Muffler Stay Stay |
| X3-01 | Spiral Bevel Gear 43T |
| X3-02 | Spiral Bevel Gear 13T |
| X3-03 | Diff. Gear 10Tx4 & 20Tx2 |
| X3-04 | Front Drive Shaft Set (CVD) |
| X3-04A | Front Drive Shaft 107.5mm CVD |
| X3-05 | Rear Drive Shaft Set (CVD) |
| X3-05A | Rear Drive Shaft 105mm (CVD) |
| X3-06 | Drive Shaft Insert Pin (2.5×12.8) |
| X3-07 | Wheel Axle (CVD) |
| X3-08 | Front Anti-Roll Bar 2.3mm, Black |
| X3-09 | Fear Anti-Roll Bar 2.3mm, Black |
| X3-12 | 4x66mm Arm Shaft |
| X3-13 | 3.5x45.8 Rear Hub Shaft |
| X3-14 | Steering King Pin |
| X3-15 | Front Arm Bushing |
| X3-16 | Servo Saver Post |
| X3-17 | Alum. Servo Saver Tube |
| X3-18 | Servo Saver Spring |
| X3-19-BK | Servo Saver Adjuster / 12×1.7 O-Ring |
| X3-20 | Servo Saver Connecting Plate B |
| X3-21 | Servo Saver Screws |
| X3-22 | Servo Saver Bushing |
| X3-23 | Brake Pads |
| X3-24 | Brake Disk (Fiber-Glass) 27mm |
| X3-25 | Brake Cam |
| X3-26 | Brake Pads Spring |
| X3-27 | Brake Pads Screw |
| X3-28 | Brake Rod Spring |
| X3-29-BK | 16mm shock Cap(Black) |
| X3-30 | Shock Mount |
| X3-31 | 7×8.5mm Ball & Socket |
| X3-32 | 7×12mm Ball & Socket |
| X3-33 | Hex 4mm Ball & Socket |
| X3-34 | 2.5×11.8 Pins |
| X3-35 | 2.5×12.8 Pins |
| X3-36 | Brake Link 1.8×95mm |
| X3-37-BK | Engine Mount R.L(Black) |
| X3-38 | Diff. Gasket 31×20×0.3 |
| X3-39 | Engine Screws 4×8mm |
| X3-40 | 4×10 Round Head Set Screw |
| X3-42 | X3S Fuel Tank |
| X3-43 | Diff. Case |
| X3-44 | Gear Case |
| X3-45 | Front Lower Arms L.R |
| X3-46 | Suspension Bracket Insert |
| X3-47 | Steering Knuckle Arm L.R |
| X3-48 | Front C Hub L.R |
| X3-49 | Body Post/Center Brace |
| X3-50 | Plastic Rod End |
| X3-51 | Servo Saver Set/Front Top Deck |
| X3-52 | Front Bumper/Rear Mud Guard |
| X3-53 | Rear Lower Arms L.R |
| X3-54 | Rear Hub L.R |
| X3-55 | Rear Wing Mount |
| X3-57 | Side Guard L.R |
| X3-58 | Receiver/Battery Box |
| X3-59 | Throttle/Steering Level Set |
| X3-60 | 1/8 Air Filter / Foam |
| X3-60A | Air Filter Foam |
| X3-61 | Bearing 8×14×4 |
| X3-62 | Bearing 13×20×4 |
| X3-63 | Screw Bag |
| X3-64 | Gear Box Dust Seal |
| X3-83 | Front Top Deck/Cen. Top |
| X3.6-04 | CNC 7075-5mm Front Shock Tower |
| X3.6-05 | CNC 7075-5mm Rear Shock Tower |
| X3.6-06 | CNC 7075-3mm Lightweight Chassis |
| X3.6-09 | Steel Spur Gear 50T |
| X3.6-11 | X3 SABRE 3.0 EVO Body |
| X3.6-13 | Carbon Center Diff Top Plate |
| X3.6-14 | Air Filter Supporter |
| X3.6-15A | Center CVD Drive Shaft Set (Front)97.5mm |
| #315A | Front Shock Shaft(short) |
| X3.6-16 | Center CVD Drive Shaft Set (Rear)117mm |
| #316A | Rear Shock Shaft(long) |
| X3.6-16A | Center CVD Drive Shaft (Rear)117mm |
| #363 | Alum. Diff Cross Pin (Hard-Coated) |
| X3.6-17 | Center Diff Down plate |
| #373-BK | Fuel Tank Lid Opener |
| X3GT-03A | CNC 7075 Suspension Bracket, RF |
| #374 | 3×20 Left Hands Threaded |
| X3GT-03B | CNC 7075 Suspension Bracket, RR |
| #380-W | Wing(White) |
| X3S-04 | Diff. Cap Joint (Lightweight) |
| #387A | 16mm Front Shock Body(short) |
| X3S-05 | CNC 7075 Chassis Brace(F/R) |
| #387B | 16mm Rear Shock Body(long) |
| X3S-05A | CNC 7075 Chassis Brace(F) |
| #387D-BK | 16mm Shock Spring Adjuster (Black) |
| X3S-05B | CNC 7075 Chassis Brace(R) |
| #387E | 10×1 mm O-Ring |
| X3S-06 | CNC 7075 Suspension Bracket, FF |
| #387F | 19×1.5mm O-Ring |
| X3S-07 | CNC 7075 Suspension Bracket, FR |
| #387G | Plastic Shock Spring Holder |
| X3S-10 | Center CVD Cap Joint |
| #387P | 16mm Shock Piston |
| XT-30B | Fuel Tank Post |
| #387S | Repair Kit for Shock Shafts |
| #139 | Manifold Spring |
| #388 | 16mm Pressure Top(Orange) |
| #150-BK | Switch Cover, Black |
| #401-W | Dish Wheel(White) |
| #155B | Body Clips |
| #406A | Air Filter Connector, S Shape |
| #158-BK | Alum. Stopper |
| #407A | 3-Pin Flywheel, 9mm(Gold) |
| #159-BK | Fuel Tube, Black |
| #407B | Clutch Shoes, (Red) |
| #234Y | Ball Bearing 5×8×2.5 |
| #407C | Clutch Spring 1.0mm. (Black) |
| #254-BR | Fule Filter (Brown) |
| #407E | SG Shaft Nut |
| #264B | Taper Cone 7mm Brass |
| #411 | Shock Spring(White with Red Pod) |
| #267D | Ball Bearing 8×16×5 |
| #425 | R-PIN(R5) |
| #267E | 2.5×16.8 Pin |
| SB2.5x5 | Round Head Hex Screw 2.5x5 |
| SB2.5x8 | Round Head Hex Screw 2.5x8 |
| SB3x5 | Round Head Hex Screw 3x5 |
| SB3x8 | Round Head Hex Screw 3x8 |
| SB3x10 | Round Head Hex Screw 3x10 |
| SB3x12 | Round Head Hex Screw 3x12 |
| SB3x15 | Round Head Hex Screw 3x15 |
| SB3x18 | Round Head Hex Screw 3x18 |
| SB3x20 | Round Head Hex Screw 3x20 |
| SB3x22 | Round Head Hex Screw 3x22 |
| SB3x25 | Round Head Hex Screw 3x25 |
| SB3x35 | Round Head Hex Screw 3x35 |
| SB4x15 | Round Head Hex Screw 4x15 |
| SB4x18 | Round Head Hex Screw 4x18 |
| SS3x3 | Set Screw 3x3 |
| SS3x6 | Set Screw 3x6 |
| SS4x4 | Set Screw 4x4 |
| SS4x6 | Set Screw 4x6 |
| SNN2.6 | Nylon Nut 2.6mm |
| SNN3 | Nylon Nut 3mm |
| SNN4 | Nylon Nut 4mm |
| SW2.6x6x0.5 | Washer 2.6x6x0.5 |
| SW3x6x0.5 | Washer 3x6x0.5 |
| SW3x8x0.5 | Washer 3x8x0.5 |
| SW4x10x0.15 | Washer 4x10x0.15 |
| SW5x8x0.3 | Washer 5x8x0.3 |
| SW8x12x0.3 | Washer 8x12x0.3 |
| SWS3x5 | Spring Washer 3x5mm |
| SC2x8 | Cap screw 2x8 |
| SC2x12 | Cap screw 2x12 |
| SC3x5 | Cap screw 3x5 |
| SC2x12 | Cap screw 2x12 |
