Sparko F8 Parts List
Sparko F8 Parts List
Source: Sparko
Part numberPart name
F80001SPARKO F8 1/8 NITRO BUGGY KIT
F80002Shock Set for Front (Not Assembled)(2pcs)
F80003Shock Set for Rear (Not Assembled)(2Pcs)
F80004Differential Set Center
F80005Differential Set F/R
F80006Air Filter Set
F80007Brake Linkage Set
F80008Cluth Set
F80009Front Sway Bar Set 2.0/2.3/2.5/2.8mm
F80010Rear Sway Bar Set 2.4/2.6/2.8/3.0mm
F81001Steering Bellcrank Set(with Servo Horn)
F81002Front Lower Suspension Arms (Left & Right)
F81004Front Upper Suspension Arms Set x2
F81005Sway Bar Ball End Set (4pcs)
F81006Front Body Mount
F81007BK1/8 Wing-Black
F81007WHOP1/8 Wing-White
F81007YLOP1/8 Wing-Yellow
F81008Fuel Tank
F81009Plastic Arm Holder Insert Set (2set)
F81010Plastic steering Shim 1mm (4pcs)
F81011F/R Gearbox Set
F81012F/R Differential Case
F81013Center Diff. Mount Set x2
F81014Side Guards
F81015Rear Lower Suspension Arms (Left & Right)
F81017Rear Hubs & Insert Set x2
F81018Bearing Spacers (4pcs)
F81019Rear Upper Arm Linkage Ball End Set x2
F81020Tall Wing Mount
F81021Front Bumper (2pcs)
F81022Rear Body Mount
F81023Antenna Tube Set
F81024Receiver Box
F81025Front Steering Linkage Ball End Set x2
F81026Spring Cups & Shock Rod Ends Set x2
F81027Shock Cap Bushings (4pcs)
F81028CNC Delrin Shock Cartridge Set x2
F81029Big Bore Tapered Shock Piston 6x1.3mm (2pcs)
F81030Big Bore Tapered Shock Piston 6x1.4mm (2pcs)
F81031Buggy Body (Clear)
F81032Center Differential Case
F81033Servo Horn Set
F81034Chassis Brace Set
F81035Rear Upper Arm Linkage Ball End Short x 4
F82001Differential O-Rings (6pcs)
F82002Shock Bladder (2pcs)
F82003Shock seal O-Rings (4pcs)
F82004Shock Spring Adjust Nut O-Ring (4pcs)
F82005Shock Boots Front (4pcs)
F82006Shock Boots Rear (4pcs)
F82007OPDustproof Bush for Receiver Box Set x2
F83001-30Carbon Fiber Steering Knuckle Plate(R=L) 3.0mm (2pcs)
F83002-15Carbon Fiber Front Upper Arm Inserts (R=L) 1.5mm (4pcs)
F83002-20OPCarbon Fiber Front Upper Arm Inserts (R=L) 2.0mm (4pcs)
F83003-30Carbon Fiber Front Top Plate 3.0mm
F83004-25Carbon Fiber Center Diff. Plate 2.5mm
F83005-25Carbon Rear Hub Link 2.5mm (4pcs)
F83006-15OPCarbon Front Arm covers 1.5mm - 2pcs
F83006-20OPCarbon Front Arm covers 2.0mm - 2pcs
F83007-15OPCarbon Rear Arm covers 1.5mm - 2pcs
F83007-20OPCarbon Rear Arm covers 2.0mm - 2pcs
F83008-15OPCarbon Rear Brace covers 1.5mm - 2pcs
F83008-20OPCarbon Rear Beace covers 2.0mm - 2pcs
F83009-150PCarbon Wing Mount covers 1.5mm - 2pcs
F83009-200PCarbon Wing Mount covers 2.0mm - 2pcs
F840017075Aluminum Steering Bellcrank
F840027075Aluminum Steering Plate
F84003Aluminum Servo Saver Post (Hard Anodizing)
F84004Aluminum Servo Saver Nut with Screw Fixed
F84005Aluminum Wheel Nut(Hard Anodizing) (4pcs)
F84006Aluminum Wheel Hub Axil(L4.5mm)17mm(Hard Anodizing)(2pcs)
F840077075Aluminum Arm Mount A(Dark Blue)
F840087075Aluminum Upper Link Mount (Dark Blue)
F840097075Aluminum Front Shock Tower (Dark Blue)
F84010Aluminum Adjuster Knob 8mm (4pcs)
F840117075Aluminum Steering Block
F840127075Aluminum Caster Block (Left & Right)(16°)
F840147075Aluminum Arm Mount B(Dark Blue)
F840157075Aluminum Arm Mount C(Dark Blue)
F84016Pinion Gear Stopper 5x7x5.1mm (4pcs)
F840177075Aluminum Chassis (Hard Anodizing)
F840187075Aluminum Rear Shock Tower (Dark Blue)
F840197075Aluminum Arm Mount D(Dark Blue)
F840207075Aluminum Engine Mount Set
F84021Aluminum Clutch Shoes & 1.0mm Spring (3pcs)
F84022Aluminum Shock Tower Washers (Titanium Color)
F840237075Aluminum Shock Caps (2pcs)
F840247075Aluminum Shock Body Seal Retainer (2pcs)
F840257075Aluminum Spring Collars (2pcs)
F840267075Aluminum Front Shock Body (Hard Anodizing)(2pcs)
F840277075Aluminum Rear Shock Body (Hard Anodizing)(2pcs)
F840281/8 Scale Flywheel
F84029OP7075Aluminum Front Brace (Dark Blue)
F84030OP7075Aluminum Rear Brace (Dark Blue)
F84031OP7075Aluminum (Dark Blue)
F84032OP7075Aluminum Caster Block (Left & Right)(20°)
F84034OP7075Aluminum Arm Mount D +2 (Dark Blue)
F84035OP7075Servo Horn Steering (Dark Blue)
F84036OP7075Servo Horn Throttle (Dark Blue)
F84037OP7075Center Diff. Mount
F85001Body Clip
F85002Sevro Saver Spring
F85003Sevro Saver Shaft(2pcs)
F85004Universal Cross Drive Shaft Set (92.5mm)
F85005Pin M3.0x16.8mm (4pcs)
F85006Rear Upper Arm Ball Stud(4pcs)
F85007Lower Arm Hinge Pin(70mm)(2pcs)
F85008Upper Arm Hinge Pin(43mm)(2pcs)
F85009Upper Arm Adjustment Screw(2pcs)
F85010Sway Bar Ball Stud(4pcs)
F85011-1Shock Ball Stud Offset 1mm for Front (2pcs)
F85011-2Shock Ball Stud Offset 2mm for Rear (2pcs)
F85012Hard Front Lower Suspension Shaft Screw (2pcs)
F85013Spindle Carrier Hinge Insert (4pcs)
F85014Spindle Carrier Hinge Pins (4pcs)
F85015Differential Outdrive (2pcs)
F85016Center Differential Outdrives (2pcs)
F85017Front/Rear Differential Outdrives (2pcs)
F85018Internal Differential Gear Set (4+2pcs)
F85019Shock Pins (4)
F85020Differential Cross Pins (6pcs)
F85021Pin M2.2x9.8mm (4pcs)
F85022Sevro Steering Turnbuckle M3x30mm (2pcs)
F85023Shock Ball Stud 6xL6.7mm (4pcs)
F85024Brake Pad Set (4pcs)
F85025Brake Pad Spring(4pcs)
F85026Brake Lever (2pcs)
F85027Brake Cam Set
F85028Brake Rotor Set (2pcs)
F85029Center Rear Dogbone 115mm
F85030Center Rear Dogbone 88mm
F85032Rear Outter Hinge Pins (2pcs)
F85033Camber Turnbuckle 5x45mm (2pcs)
F85034Rear Upper Arm Ball Stud 7.0mm Hex (4pcs)
F85035-13Clutch Bell (13T)
F85036Exhaust Wire Mount Set
F85037Steering Turnbuckle M4x40mm (2pcs)
F85038Steering Turnbuckle Ball Set (4pcs)
F85040Front Shock Shaft (2pcs)
F85041Rear Shock Shaft (2pcs)
F85042Hex Shanked Button M3x13.7mm (4pcs)
F85043Down Stop Screw M4x10mm(4pcs)
F850441/8 Scale Flywheel Nut
F85045I-Head Screw Thin M4x8mm (10pcs)
F85046-46Center Gear 46T with Differential Seal
F85047-43Crown Gear 43T with Differential Seal
F85048-13Pinion Gear13T
F85049-10Clutch Spring 1.0mm (3pcs)
F85050-20OPFront Sway Bar 2.0mm
F85050-23Front Sway Bar 2.3mm
F85050-25Front Sway Bar 2.5mm
F85050-28OPFront Sway Bar 2.8mm
F85051-24OPRear Sway Bar 2.4mm
F85051-26Rear Sway Bar 2.6mm
F85051-28Rear Sway Bar 2.8mm
F85051-30OPRear Sway Bar 3.0mm
F85052-H62Shock Spring for Front Hard L=62mm(2pcs)
F85052-M62OPShock Spring for Front Medium L=62mm(2pcs)
F85052-S62OPShock Spring for Front Soft L=62mm(2pcs)
F85053-H80OPShock Spring for Rear Hard L=80mm (2pcs)
F85053-M80Shock Spring for Rear Medium L=80mm (2pcs)
F85053-S80OPShock Spring for Rear Soft L=80mm (2pcs)
F89001Servo Spring Dusty Protect Sponge(2pcs)
F89002Differential Seals Set (2+1pcs)
F89003Air Filter Foam (9pcs)
F89004-BKBody Sticker-Black and White
F89004-PKOPBody Sticker-Pink for Optional
F89004-OGOPBody Sticker-Orange for Optional
F89004-YLOPBody Sticker-Yellow for Optional
F89005-BKWing Sticker-Black and White
F89005-PKOPWing Sticker-Pink for Optional
F89005-OGOPWing Sticker-Orange for Optional
F89005-YGOPWing Sticker-Yellow for Optional
F89006Body Shell Window Masks
F89007SPARKO F8 1/8 Buggy User Manual
BF030625Flange Ball Bearing 3x6x2.5mm (4pcs)
BO050825Ball Bearing 5x8x2.5mm (4pcs)
BO051004Ball Bearing 5x10x4mm (4pcs)
BO051304Ball Bearing 5x13x4mm (4pcs)
BO061003Ball Bearing 6x10x3mm (4pcs)
BO081605Ball Bearing 8x16x5mm (4pcs)
NF03BKFlanged Locknut M3 (10pcs)
NO025SLNut Lock M2.5mm (10pcs)
NO03BKNut Lock M3 (10pcs)
NO04BKNut Lock M4 (10pcs)
SB02505BKBall Screw M2.5x5mm (10pcs)
SB02508BKBall Screw M2.5x8mm (10pcs)
SB0305BKBall+I16 Screw M2.5x8+F15:M15mm (10pcs)
SB0306BKBall Screw M3x6mm (10pcs)
SB0308BKBall Screw M3x8mm (10pcs)
SB0310BKBall Screw M3x10mm (10pcs)
SB0312BKBall Screw M3x12mm (10pcs)
SB0314BKBall Screw M3x14mm (10pcs)
SB0315BKBall Screw M3x15mm (10pcs)
SB0316BKBall Screw M3x16mm (10pcs)
SB0320BKBall Screw M3x20mm (10pcs)
SB0323BKBall Screw M3x23mm (10pcs)
SB0325BKBall Screw M3x25mm (10pcs)
SC0206BKCap Screw M2x6mm (10pcs)
SC03012BKCap Screw M3x12mm(10pcs)
SC0308BKCap Screw M3x8mm (10ps)
SC0310BKCap Screw M3x10mm (10pcs)
SC0312BKCap Screw M3x12mm (10pcs)
SC0316BKCap Screw M3x16mm (10pcs)
SC0322BKCap Screw M3x22mm (10pcs)
SC0323BKCap Screw M3x23mm (10pcs)
SC0325BKCap Screw M3x25mm (10pcs)
SC0328BKCap Screw M3x28mm (10pcs)
SF02046BKFlat Screw M2.0x4.6mm 1.5 Hex (10pcs)
SF0306BKFlat Screw M3x6mm (10pcs)
SF0308BKFlat Screw M3x8mm (10pcs)
SF0310BKFlat Screw M3x10mm (10pcs)
SF0312BKFlat Screw M3x12mm (10pcs)
SF0314BKFlat Screw M3x14mm (10pcs)
SF0335BKFlat Screw M3x35mm (10pcs)
SF0408BKFlat Screw M4x8mm (10pcs)
SF0410BKFlat Screw M4x10mm (10pcs)
SF0414BKFlat Screw M4x14mm (10pcs)
SF0416BKFlat Screw M4x16mm (10pcs)
SS0303BKSet Screw M3x3mm Set (10pcs)
SS0304BKSet Screw M3x4mm Set (10pcs)
SS0404BKSet Screw M4x4mm Set (10pcs)
SS0504BKSet Screw M5x4mm Set (10pcs)
WO0260660Shock Piston Washer 2.6x6x0.6mm (10pcs)
WO030801Shim 3x8x1mm (10pcs)
WO030510Shim 3x5x0.1mm (10pcs)
WO0351020Differential Shim 3.5x10x0.2mm (12pcs)
WO050840Shim 5x8xT0.4mm (10pcs)
WO050880Shim 5x8xT0.8mm Shim (10pcs)
WO051230Differential Shim 5x12x0.3mm (6pcs)
WO060830Shim 6x8x0.3mm (10pcs)
WO061020Differential Shim 6x10x0.2mm (10pcs)
WO061030Differential Shim 6x10x0.3mm (10pcs)
WO081020Hex Shim 8x10x0.2mm (10pcs)
WO131620Differential Shim 13x16x0.2mm (10pcs)
WS0305510Spring Washer M3x5.5x1mm(10pcs)
