Tekno NT48 2.0 Manual

Full parts list

Front End

Part #	Description
TKR8073	CV Rebuild Kit (front/rear, for 2 axles)
TKR9018	Front Bumper (2pcs)
TKR9041	Spindles and Bearing Spacers (L/R)
TKR9043	Spindle Carrier Hinge Pins (steel, 4pcs)
TKR9048A	Spindle Carriers (revised, L/R, aluminum, 15 degree)
TKR9428	Shock Tower (front, 7075 CNC, GM ano)
TKR9436	Suspension Arms (front, 2pcs)
TKR9485	Sway Bar Set (FRONT)

Rear End

Part #	Description
TKR9040	Rear Hubs and Bearing Spacers (L/R)
TKR9165	Rear Arm Hinge Pin Inserts
TKR9166	Rear Hub Roll Center Inserts
TKR9429	Shock Tower (rear, 7075 CNC, GM ano)
TKR9430	Suspension Arms (rear, 2pcs)
TKR9495	Sway Bar Set (REAR)

Suspension

Part #	Description
TKR5049A	Pivot Balls (6.8mm, no flng, sway bar, shck ends, almnm, 4pcs)
TKR5079A	Stabilizer Balls (6.8mm, sway bars, aluminum, 4pcs)
TKR5165	V2 Hinge Pin Inserts, Wheelbase Shims
TKR5187B	Rod Ends (hard, 6.8mm, 8pcs)
TKR6140C	Locking Shock Rod End and Spring Perch Set (revised)
TKR6252	Turnbuckle (M3 thread, 40mm length, 2pcs)
TKR8052A	Pivot Balls (6.8mm, camber, str links, almnm, centered, 4pcs)
TKR9017	Sway Bar and Bulkhead Acc
TKR9020	Hinge Pins (inner, front/rear)
TKR9034	Hinge Pins (outer, rear, 2pcs)
TKR9055	Hinge Pin Bushings (8pcs)
TKR9423	Turnbuckle (M4 thread, 100mm length, 4mm adjustment, 2pcs)
TKR9450	Turnbuckle (M5 thread, 108mm length, 5mm adjustment, 2pcs)
TKR9461	Hinge Pin Brace (CNC, 7075, A Block)
TKR9462	Hinge Pin Brace (CNC, 7075, B Block)
TKR9463	Hinge Pin Brace (CNC, 7075, C Block)
TKR9464	Hinge Pin Brace (CNC, 7075, D Block)

Steering

Part #	Description
TKR1250	Steering Link Screws (black, steel, 2pcs)
TKR5101X	Servo Saver Spring (HD)
TKR5103	Servo Saver Post (aluminum, gun metal ano)
TKR5122	Steering Rack Bushings (aluminum, gun metal ano, 2pcs)
TKR5230	Steering Linkage (M3x18mm threaded rod, 10pcs)
TKR5231	Servo Saver Nut and Spring
TKR8100B	Ackerman Plate (7075)
TKR9102A	Steering Posts (aluminum, gun metal ano)
TKR9104	Bell Cranks and Top Plate

Drivetrain

Part #	Description
TKR5297	Universal Driveshaft (center, rear)
TKR8070	Stub Axles (hardened steel, 2pcs)
TKR9296	Universal Driveshaft (center, front, 87.5mm)
TKR9412	Gearbox (front)
TKR9415	Spur Gear (48t, steel, CNC, lightened)
TKR9416	Gearbox (rear)
TKR9472	Driveshafts (F/R, hardened steel, 2pcs)

Differentials

Part #	Description
TKR1222	13x16x.1mm Diff Shims (10pcs)
TKR5144	Differential O-Rings (6pcs)
TKR5145B	Differential Shims (revised, 6x17mm, 6pcs)
TKR9112	Differential Outdrives (center, 2pcs)
TKR9113	Differential Case (center)
TKR9114	Differential Outdrives (F/R NB/NT48 2.0, F/C/R EB/ET48 2.0, 2pcs)
TKR9115	Differential Case (F/R NB/NT48 2.0, F/C/R EB/ET48 2.0)
TKR9143	Differential Seals (3pcs)
TKR9149	Differential Cross Pins (6pcs)
TKR9150	Differential Gear Set (internal gears only)
TKR9310	Split Center Diff Mount
TKR9452	Differential Ring Gear (40t, F/R, CNC, use with TKR9453)
TKR9453	Diff Pinion (9t, F/R, CNC, use with TKR9452)

Brakes

Part #	Description
TKR5058A	Pivot Balls (5.8mm, no flange, brake/steering link, aluminum, 4pcs)
TKR5345B	Brake Disc (steel, revised, 1pc)
TKR5368B	Brake Post Spring (revised, xtra stiffy, 4pcs)
TKR9059	Rod End Set (brake/steering/sway bar linkage)
TKR9213	Brake Posts (steel, 4pcs)
TKR9215B	Brake Cam Set (revised, F/R, steel)
TKR9314	Metallic Brake Pads (2pcs)
TKR9392	Throttle, Brake Linkage

Engine & Fuel

Part #	Description
TKR4213	Clutch Bell (13t)
TKR5331	Throttle Pivot Ball Assembly (CNC)
TKR5350	Flywheel (4-shoe)
TKR5351	Clutch Shoes (7075, 4pcs)
TKR5353	Clutch Springs and Hardware Set
TKR9317	Radio Box and Throttle Servo Mount
TKR9321	Exhaust Wire Mount Set (CNC)
TKR9323	Engine Mounts (CNC, 7075)
TKR9343	Air Filter Set (hose, filter, housing)
TKR9363	Air Filter Foams (inner, outer, pre-oiled, 3pcs each)
TKR9440	Fuel Tank and Accessories (ROAR legal)

Wheels & Hubs

Part #	Description
TKR5116	Wheel Nuts (17mm, serrated, gun metal ano, M12x1.0, 4pcs)
TKR9671	Wheel Hubs (+2mm offset, 17mm, gun metal ano, w/pins, 2pcs)
TKR9673	Wheel Hubs (+4mm offset, 17mm, gun metal ano, w/pins, 2pcs)

Chassis & Body

Part #	Description
TKR1235	Body Clips (10pcs)
TKR5401	Body Mount Set
TKR8292W	Lightweight Wing (ROAR/IFMAR legal, white)
TKR9181T	Tall Wing Mount and Body Mounts
TKR9324	Mud Guard and Battery Box Set (L/R)
TKR9328B	Chassis Brace Set (revised)
TKR9397	Mudguard Adapters (L/R)
TKR9402	Chassis (7075, hard anodized)
TKR9445A	Body (w/ window mask)
TKR9445N	Headlights / Nose Cone
TKR9446	Decal Sheet

Electronics

Part #	Description
TKR5126	Antenna tube (universal, w/ caps, 5pcs)

Shocks

Part #	Description
TKR1240	Lower Shock Mount Screws (2 CW thread, 2 CCW thread)
TKR6009	Shock O-Ring and Bladder Set (for 2 shocks)
TKR6013	Shock Adjustment Nuts (aluminum, gun metal ano, 2pcs)
TKR6015	Shock Cartridge Caps (aluminum, gun metal ano, 2pcs)
TKR6016	Shock Body (rear, aluminum, hard ano, 2pcs)
TKR6017	Shock Shafts (rear, steel, 2pcs)
TKR6060	Shock Body (rear, x-long, aluminum, hard ano, 2pcs)
TKR6061	Shock Shafts (rear, x-long, steel, 2pcs)
TKR6144	Shock Boots (long length, 2pcs)
TKR6145	Shock Boots (XL length, rear ET/NT, 2pcs)
TKR6146	Shock Cartridge Set (CNC, Delrin)
TKR6180	Shock Piston (CNC, flat/flat, 4x1.2 + 4x1.3)
TKR8702	Shock Caps (7075, emulsion/vented/standard, black ano, 2pcs)
TKR8725	Emulsion O-ring Set (4x cap seals, 8x emulsion o-rings, for 16mm shocks)
TKR8727	Shock Standoffs (2pcs, requires TKR8730)
TKR8730	Shock Cap Bushings (4pcs, requires TKR8727)

Bearings

Part #	Description
TKRBB050825	Ball Bearing (5x8x2.5mm, 4pcs)
TKRBB05104	Ball Bearing (5x10x4, 4pcs)
TKRBB05114	Ball Bearing (5x11x4, 4pcs)
TKRBB05134	Ball Bearing (5x13x4, 4pcs)
TKRBB05145	Ball Bearing (5x14x5, shielded, 4pcs)
TKRBB06103	Ball Bearing (6x10x3, 4pcs)
TKRBB08165	Ball Bearing (8x16x5, 4pcs)
TKRBB08165F	Ball Bearing (8X16x5mm, flanged, shielded, 4pcs)
TKRBB15214	Ball Bearing (15x21x4, shielded, 4pcs)

Hardware

Part #	Description
TKR1200	M2.5 Locknuts (zinc finish, 10pcs)
TKR1201	M3 Locknuts (black, 10pcs)
TKR1211	M3 Locknuts (flanged, black, 10pcs)
TKR1212	M4 Locknuts (flanged, black, serrated, 10pcs)
TKR1220	M3 Countersunk Washers (aluminum, natural, 10pcs)
TKR1221	M3x8mm Washer (black, 10pcs)
TKR1226	5x7x.2mm shims (10pcs)
TKR1228	M4 Countersunk Washer (black, 10pcs)
TKR1238	Droop Adjustment Screws (M4x10mm, 8pcs)
TKR1248	M2x4mm Cap Head Screws (black, 10pcs)
TKR1301	M2.5x6mm Flat Head Screws (black, 10pcs)
TKR1303	M2.5x10mm Flat Head Screws (black, 10pcs)
TKR1322	M3x8mm Flat Head Screws (black, 10pcs)
TKR1323	M3x10mm Flat Head Screws (black, 10pcs)
TKR1324	M3x12mm Flat Head Screws (black, 10pcs)
TKR1325	M3x14mm Flat Head Screws (black, 10pcs)
TKR1342	M4x8mm Flat Head Screws (black, 10pcs)
TKR1343	M4x10mm Flat Head Screws (black, 10pcs)
TKR1344	M4x12mm Flat Head Screws (black, 10pcs)
TKR1346	M4x15mm Flat Head Screws (black, 10pcs)
TKR1349	M4x20mm Flat Head Screws (black, 10pcs)
TKR1401	M3x6mm Button Head Screws (black, 10pcs)
TKR1402	M3x8mm Button Head Screws (black, 10pcs)
TKR1403	M3x10mm Button Head Screws (black, 10pcs)
TKR1407	M3x16mm Button Head Screws (black, 10pcs)
TKR1443	M4x10mm Button Head Screws (black, 10pcs)
TKR1444	M4x12mm Button Head Screws (black, 10pcs)
TKR1445	M4x14mm Button Head Screws (black, 10pcs)
TKR1522	M3x8mm Cap Head Screws (black, 10pcs)
TKR1523	M3x10mm Cap Head Screws (black, 10pcs)
TKR1525	M3x14mm Cap Head Screws (black, 10pcs)
TKR1528	M3x18mm Cap Head Screws (black, 10pcs)
TKR1529	M3x20mm Cap Head Screws (black, 10pcs)
TKR1532	M3x35mm Cap Head Screws (black, 10pcs)
TKR1534	M3x22mm Cap Head Screws (black, 10pcs)
TKR1601	M3x4mm Set Screws (black, 10pcs)
TKR1603	M5x4mm Set Screws (black, 10pcs)
TKR1605	M3x10mm Set Screws (black, 10pcs)
TKR1609	M3x3mm Set Screws (black, 10pcs)
TKR8042	Kingpin Shoulder Screws (EB/NB48.4, 4pcs)
