Gearing
Stock gearing for the Xpress Pixel Z1, with common pinions and their ratios.
| Pinion | Spur ÷ pinion | FDR |
|---|---|---|
| 4T | 13.25 | 13.25 |
| 5T | 10.60 | 10.60 |
| 6T | 8.83 | 8.83 |
| 7T | 7.57 | 7.57 |
| 8T | 6.63 | 6.63 |
| 9T | 5.89 | 5.89 |
| 10T | 5.30 | 5.30 |
| 11T | 4.82 | 4.82 |
| 12T | 4.42 | 4.42 |
| 13T | 4.08 | 4.08 |
| 14T | 3.79 | 3.79 |
| 15T | 3.53 | 3.53 |
| 16T | 3.31 | 3.31 |
Shaded rows are the pinions most 1/24-1/28 2WD touring/gt setups run on the stock spur.
What pinion should I run?
Tell us your motor and track and get a starting pinion for the Xpress Pixel Z1, with the range racers in the class run.
Get a recommendation →Shop pinion gears at AMain →What pinion gear should I use on the Xpress Pixel Z1?
It depends on your motor and the track. Racers in the 1/24-1/28 2WD touring/gt class run a 6–14 tooth pinion in most setups, usually on a 53T spur for a final drive ratio near 5.30. Hotter motors (lower turns, higher Kv) take a smaller pinion; tight tracks gear down, open tracks gear up. For a starting pinion matched to your motor, use the So Dialed Pinion Recommender with the Pixel Z1 selected.
What is the internal ratio (transmission ratio) of the Xpress Pixel Z1?
The Pixel Z1 has an internal ratio of 1:1. Final drive ratio = spur ÷ pinion × 1. With the stock 53T spur, a 4T pinion gives an FDR of 13.25 and a 16T gives 3.31.
How many teeth is the stock spur gear on the Xpress Pixel Z1?
53 teeth. Changing the spur moves every pinion's ratio at once; most racers leave the spur and tune with the pinion.
Kit setup
Kit shock setup. Part numbers link to AMain.
- Front
- 5T Black #XP-11333 →
- Center
- 7T Black #XP-11334 →
- Side
- 5T Black #XP-11333 →
What springs does the Xpress Pixel Z1 come with?
The kit springs are 5T Black (#XP-11333) front, 7T Black (#XP-11334) center, 5T Black (#XP-11333) side. Stiffer springs suit high grip and big jumps; softer springs add grip on slick or bumpy tracks.
