| Part number | Part name |
|---|---|
| 6121 | VIPER single seat buggy |
| 6122 | ASSOCIATED RC10T TRUCK. Fits RC10 after conversion to RC10T |
| 6130 | RC10T ASSOCIATED TEAM TRUCK (slightly narrower than #6122 kit body). Fits RC10 after conversion to RC10T |
| 6132 | T2 RACING TRUCK BODY, clear Lexan |
| 6160 | PROTECH BUGGY |
| 6161 | SIDEWINDER single seat buggy |
| 6162 | COUGAR OUTLAW oval full-fendered |
| 6163 | SPRINTER #1 |
| 6173 | PROTECH II updated Buggy |
| 6110 | MOLDED PLASTIC WING, neon pink |
| 6111 | MOLDED PLASTIC WING, black |
| 6112 | MOLDED PLASTIC WING, white |
| 6113 | MOLDED PLASTIC WING, neon green |
| 6114 | MOLDED PLASTIC WING, red |
| 6180 | DRIVER, clear |
| 6181 | HIGH DOWN FORCE WING KIT, includes #6182 wing, #6190 wing mounts and wire (used in current RC10 car kits) |
| 6182 | HIGH DOWN FORCE WING, 5 1/2" |
| 6183 | HIGH DOWN FORCE WING, 7" |
| 6184 | WING, small, 2 X 4.5, plastic only |
| 6185 | WING KIT, 2 X 4.5, adjustable mounts |
| 6186 | WING, large, 2.5 X 6, plastic only |
| 6187 | WING KIT, 2.5 X 6, adjustable mounts |
| 6188 | SPRINT WING , with side dam |
| 6189 | SPRINT WING KIT w/side dam, hardware |
| 6190 | WING MOUNTS, adjustable (Wing-Things) |
| 6193 | SUPER WING THINGS, aluminum |
| 7185 | TRUCK REAR BODY SPOILER, Lexan |
| 6196 | DECAL SHEET 6 1/2" X 6 1/2", 5 colors; misc. sponsors |
| 3817 | TEAM ASSOCIATED LOGO BUMPER STICKERS, 1 large, 1 small. Red, white, blue |
| 3818 | TEAM ASSOCIATED logo decals, black, 6 logos |
| 3819 | TEAM ASSOCIATED logo decals, white, 6 logos |
| 3807 | "RC10" DECALS, 3 sizes, fluores. red & yel |
| 3808 | "RC10T" DECALS, 3 sizes, fluores. red & yel |
| 3809 | "RC12L" DECALS, 3 sizes, fluores. red & yel |
| 3810 | "RC10L" DECALS, 3 sizes, fluores. red & yel |
| 3811 | RC10GT DECALS, 2 sizes of "RC10GT", fluores. red & yellow with "GT" in white smoke |
| 3812 | RC10T2 DECAL, 3 sizes of "RC10T2,' fluor. |
| 7195 | RC10T TRUCK DECAL SHEET, for #6122 body |
| 7196 | RC10T TEAM TRUCK DECAL SHEET, for #6130 body |
| 7198 | T2 RACING TRUCK DECAL SHEET. 8.5 x 10" 6 colors. Realism for the #6132 T2 Truck body. |
| 6160 | PROTECH BUGGY |
| 6200 | FRONT SUSPENSION KIT, no shocks |
| 6202 | FRONT SUSPENSION KIT, wide track |
| 6201 | FRONT ANTIFOLL BAR KIT |
| 6205 | FRONT A-ARMS |
| 6206 | FRONT A-ARMS, black composite material, wide track |
| 6207 | FRONT SUSPENSION MOUNT |
| 6210 | FRONT BLOCK CARRIER, 30° caster. (New standard kit) |
| 6211 | FRONT BLOCK CARRIER, 5° caster |
| 6212 | FRONT BLOCK CARRIER, 10° caster |
| 6213 | FRONT BLOCK CARRIER, 15° |
| 6214 | FRONT BLOCK CARRIER, 20° caster |
| 6215 | FRONT BLOCK CARRIER, 25° caster |
| 6216 | FRONT STEERING BLOCK |
| 6217 | INLINE STEERING BLOCK, use with 6218 |
| 6218 | INLINE FRONT AXLE, use with #6217 |
| 6219 | FRONT STUB AXLE, with clips, nuts |
| 6220 | ALUMINUM FRONT INLINE AXLES. Axle thread is now 5-40, not 4-40. Uses #6222 black nylon locknut |
| 6221 | INLINE STEERING BLOCK, for alum. axles |
| 6222 | SELF-THREADING NYLON LOCKNUT, for #6220 axles |
| 6223 | KINGPIN, with clips |
| 6224 | SHOCK PIN, with set screws |
| 6226 | HINGE PIN, inner, with clips |
| 6227 | HINGE PIN, outer, with clips |
| 6231 | FRONT SHOCK STRUT |
| 6232 | FRONT SHOCK STRUT, graphite composite |
| 6235 | 4-40 THREADED ROD, (upper link) |
| 6240 | REBUILD KIT, (screws/clips/pins etc.) |
| 6241 | FRONT END SCREW SET, 10 screws |
| 6242 | FRONT WHEEL LOCKNUT, 4-40 |
| 6250 | SERVO SAVER, linkage, tie rod kit (6-2) |
| 6255 | SERVO SAVER, plastic only, 2 complete |
| 6252 | BELL CRANK STEERING KIT, with #6253 bushings (can be used with #897 1/4" x 3/8" flanged ball bearings) |
| 6253 | BUSHING, 1/4" x 3/8" flanged for #6252 bell crank steering |
| 6254 | BELL CRANK STEERING, plastic only |
| 6256 | LINKAGE, "z"-wires and collars |
| 6257 | TIE ROD SET, with ends |
| 6258 | TIE ROD SET, rods only |
| 6259 | TURNBUCKLE, "Adjustable Tie Rod" set, with 7 turnbuckles, 14 cups |
| 6260 | TURNBUCKLE, 1" |
| 6261 | TURNBUCKLE, 1.25" |
| 6264 | TURNBUCKLE, 1.375" |
| 6262 | TURNBUCKLE, 1.65" |
| 6263 | TURNBUCKLE, 2.06" |
| 6270 | SHORT BALL END, steel (4-40 threaded ball studs), with plastic end caps |
| 6271 | SHORT BALL END, steel (4-40 threaded ball studs), with plastic end caps (6-14) |
| 6273 | LONG BALL END, steel (4-40 long threaded ball studs), with plastic end caps. 1/10" longer thread than #6270 |
| 6272 | BALL CUP DUST COVER |
| 6274 | BALL CUP, spares for 6270, 6271, nylon |
| 6280 | 8-32 X 1/2 ALUM. FLAT HEAD screw |
| 6281 | 8-32 X 7/8 ALUM. FLAT HEAD machine screw |
| 6284 | 4-40 X 1/4 ALUM. SOCKET HEAD CAP |
| 6285 | 4-40 X 1/4 SOCKET HEAD CAP, steel |
| 6288 | 4-40 X 1/4 BUTTON HEAD SOCKET screw |
| 6291 | 4-40 X 1/4 FLAT HEAD SOCKET screw |
| 6292 | 4-40 X 3/8 FLAT HEAD SOCKET screw |
| 6295 | 4-40 NUT, 6 each plain nut, nylon and steel locknut |
| 6296 | 8-32 LOCKNUT, 6 each alum. and nylon |
| 6299 | E-CLIP, for 1/8 shaft |
| 6312 | CLEAR CHASSIS PROTECTIVE SHEET to protect the chassis finish, 6 1/2" X 18" |
| 6315 | NOSE PLATE, neon hot pink |
| 6317 | NOSE PLATE, blue |
| 6318 | NOSE PLATE, neon lime green |
| 6319 | NOSE PLATE, yellow |
| 6320 | NOSE BRACE TUBES, use #6231 |
| 6321 | NOSE BRACE TUBES, black anodized |
| 6323 | REAR BULKHEAD, new updated design |
| 6325 | TRANSMISSION BRACE |
| 6593 | GRAPHITE TRANSMISSION BRACE for tranny only |
| 6327 | WING TUBE |
| 6330 | BODY MOUNT KIT, w/hardware (bag 6-5) |
| 6332 | HOOD PIN |
| 6334 | BATTERY CUP, w/straps, hardware (6-7) |
| 6335 | BATTERY HOLD-DOWN STRAP |
| 6336 | SERVO MOUNT, w/ hardware (bag 6-6) |
| 6338 | ANTENNA KIT, with hardware |
| 6339 | FIBERGLASS BATTERY HOLD DOWN STRAP for 6-cell battery pack mounted front to rear in chassis |
| 6350 | REAR SUSPENSION KIT, no shocks (bag 6-8) |
| 6351 | REAR ANTI-ROLL BAR KIT |
| 6355 | REAR A-ARM, black composite material |
| 6360 | REAR SUSP. MOUNT, 1.5° toe-in per side |
| 897 | BALL BEARING, 1/4 X 3/8 flanged. Fits #6365 and 6366 rear hub carriers. |
| 6365 | REAR HUB CARRIER, uses 1/4 X 3/8 flanged bearing #897. |
| 6366 | REAR HUB CARRIER, black composite material, 1.5° toe-in per side. Used with #6360 rear mounts gives 3° toe-in per side. Uses 1/4" x 3/8" flanged bearing #897 |
| 6370 | DOGBONE (rear half-shaft) |
| 6371 | UNIVERSAL DOGBONE AXLE use #6374 |
| 6372 | DOGBONE SPRING and spacers |
| 6373 | SPACER for #6371 |
| 6374 | REAR STUB AXLE, with roll pin |
| 6375 | ROLL PIN for stub axle (Fits only#6371 or #6374 axles) |
| 6377 | REAR SHOCK STRUT, graphite composite |
| 6378 | REAR SHOCK STRUT |
| 6380 | HINGE PIN, rear, inner |
| 6381 | HINGE PIN, rear, outer |
| 7356 | HINGE PIN, rear, inner |
| 6385 | 4-40 X 1 1/4 threaded rod (upper link) |
| 6387 | AXLE BUSHING, 1/4 X 3/8 X .400 and washer. Fits #6365 and #6366 rear hub carriers |
| 6388 | CONE WASHER, 1/4 X .400 X .006 |
| 6390 | KNOCKOFFS, rear wheel 8-32 nylon wing nuts |
| 6394 | REBUILD KIT, screws, clips, pins, etc. |
| 7364 | REAR SUSPENSION MOUNT, 0° toe-in |
| 7363 | REAR SUSPENSION MOUNT, 3° toe-in |
| 7365 | REAR HUB CARRIER, 0° toe-in per side (uses 1/4 X 3/8 unflanged bearing #7359) |
| 7358 | REAR HUB CARRIER, 3° toe-in per side (uses 1/4 X 3/8 unflanged bearing #7359) |
| 7359 | BALL BEARING, 1/4 X 3/8 unflanged, fits #7358 & 7365 rear hub carriers |
| 7360 | BUSHING, 1/4 X 3/8 unflanged, fits #7358 & 7365 rear hub carriers |
| 3438 | ALUMINUM LOCK NUT, 8-32 |
| 8182 | SPECIAL NUT, 8-32, alum. plain nut. Used for rear suspension mount |
| 6605 | HOUSING, left and right |
| 6606 | BEARING ADAPTER |
| 6607 | MOTOR MOUNTING PLATE, gold anodized. Also fits Associated transmission. |
| 6604 | MOTOR MOUNTING PLATE, black anodized. Also fits Associated transmission. |
| 6608 | GEAR DUST COVER |
| 6609 | DRIVE GEAR PIVOT |
| 6610 | IDLE GEAR PIVOT |
| 6611 | SPINE (CENTER) PLATE |
| 6612 | AXLE DRIVE GEAR |
| 6614 | IDLE GEAR, black, precision, reinforced |
| 6617 | DIFF TUBE, w/inner hub & PTFE bushings |
| 6618 | DIFF SHAFT, with left dif pinion |
| 6619 | DIFF BALL, 1/8" Carbide |
| 6620 | DIFF PINION, left (small hole) |
| 6621 | DIFF PINION, right, (large hole) |
| 6623 | DIFF PTFE BUSHING |
| 6624 | DIFF OUTER HUB |
| 6625 | DIFF DRIVE RING |
| 6626 | DIFF BALL |
| 6627 | DIFF THRUST BEARING SET |
| 6587 | TORQUE CONTROL SPRING & NUT |
| 6629 | DIFF LOCKNUT, 5-40 |
| 6630 | TRANSMISSION OILITE BUSHING SET |
| 6633 | FELT SEAL |
| 6634 | TRANSMISSION E-CLIP and screw set |
| 6635 | E-CLIPS AND WASHER for #6610 |
| 6636 | SILICON DIFF GREASE, 1/4 oz tub |
| 6608 | GEAR DUST COVER |
| 6560 | 2.25:1 TRANSMISSION KIT, with bearings and Associated Torque Control |
| 6563 | COMPLETE TRANNY BALL BEARING SET |
| 6565 | TRANSMISSION CASE, left & right sides, for 2.25:1 transmission |
| 6566 | FELT GASKET |
| 6567 | COMPLETE SCREW SET |
| 6568 | SPUR GEAR SCREW |
| 6569 | MOTOR PLATE SPACER & END CAP |
| 6570 | IDLER SHAFT AND GEAR |
| 6571 | DRIVE GEAR/SHAFT Assembly, w/roll pin |
| 6572 | DRIVE SHAFT ROLL PIN |
| 6573 | DIFF THRUST WASHER |
| 6574 | PRECISION THRUST BALL, 5/64" (Replaces #6576) |
| 6575 | DIFF THRUST BOLT, THRUST BEARING COVER, dogbone spacers & Locking T-nut |
| 6577 | DIFF OUTDRIVE HUB, right, 2.25:1 |
| 6578 | DIFF OUTDRIVE HUB, left, 2.25:1 |
| 6579 | DIFF DRIVE RING, 2.25:1 |
| 6580 | DIFF GEAR, 2.25:1 |
| 6581 | CARBIDE DIFF BALL, large, 3/32" |
| 6582 | DIFF THRUST SPRING |
| 6583 | TORQUE CONTROL HUB, inner |
| 6584 | TORQUE CONTROL HUB, outer |
| 6585 | CLUTCH DISK |
| 6594 | THRUST BEARING WASHER, replaces #6586 thrust bearing |
| 6587 | TORQUE CONTROL SPRING & NUT |
| 6588 | BLACK GREASE |
| 6589 | DIFF BEARING, 5/32 X 5/16 unflanged |
| 6590 | MOUNTING HOLE DRILL GUIDE, 2.25:1 |
| 6591 | TRANSMISSION DIFF LUBE |
| 6592 | ALLEN WRENCH SET, 1/16, 5/64, 3/32 |
| 6593 | GRAPHITE TRANSMISSION BRACE |
| 6608 | GEAR DUST COVER |
| 6901 | BALL BEARING, 3/16 X 5/16 unflanged |
| 6903 | BALL BEARING, 3/8 X 5/8 |
| 6906 | BALL BEARING, 3/16 X 3/8 |
| 6595 | COMPLETE BUSHING SET FOR TRANSMISSION |
| 6597 | BUSHING, 3/16 X 5/16 |
| 6598 | BUSHING, 5/32 X 5/16 |
| 6599 | BUSHING, 3/8 X 5/8 |
| 6599 | BUSHING, 3/16 X 3/8 |
| 6563 | COMPLETE ASSOCIATED TRANSMISSION BALL BEARING SET |
| 6901 | 3/16 X 5/16 BALL BEARING, unflanged |
| 6902 | 3/16 X 5/16 BALL BEARING, flanged |
| 6903 | 3/8 X 5/8, BALL BEARING, unflanged, PTFE sealed |
| 6905 | BALL BEARING SET for early Championship Edition RC10's with standard transmission |
| 6906 | 3/8 X 3/16 BALL BEARING, unflanged |
| 897 | 1/4 X 3/8 BALL BEARING, flanged |
| 6420 | SHOCK, rear, 1.32 STANDARD |
| 6421 | SHOCK, rear, 1.02 STANDARD |
| 6422 | SHOCK, front, 0.71 STANDARD |
| 6423 | SHOCK, front, 0.56 STANDARD |
| 6425 | BODY, rear, 1.32 STANDARD |
| 6426 | BODY, rear, 1.02 STANDARD |
| 6427 | BODY, front, 0.71 STANDARD |
| 6428 | BODY, front, 0.56 STANDARD |
| 6428 | END CAP, plastic |
| 6466 | REAR SHOCK DOWNSTOP |
| 6429 | SHOCK ASSEMBLY TOOL |
| 6440 | REBUILD KIT for Standard and Racing shocks, for 4 shocks |
| 6431 | SHOCK, rear, 1.32 RACING |
| 6432 | SHOCK, rear, 1.02 RACING |
| 6433 | SHOCK, front, .71 RACING |
| 6434 | SHOCK, front, .56 RACING |
| 6435 | BODY, long rear, 1.32 RACING |
| 6436 | BODY, short rear, 1.02 RACING |
| 6437 | BODY, long front, .71 RACING |
| 6438 | BODY, short front, .56 RACING |
| 6478 | Silver |
| 7434 | Blue, soft, oval |
| 7435 | Gold, med., oval |
| 7436 | Red, firm, oval |
| 7427 | 2.25", Green |
| 7428 | 2.25", Silver |
| 7429 | 2.0", Blue |
| 7425 | 2.0", Gold |
| 7430 | 2.0", Red |
| 8232 | Black, soft |
| 6494 | Green, med. |
| 6496 | Silver, firm |
| 6650 | SPUR GEAR, 48 tooth |
| 6665 | PRECISION MACHINED PINION, 11T |
| 6666 | PRECISION MACHINED PINION, 12T |
| 6668 | PRECISION MACHINED PINION, 14T |
| 6669 | PRECISION MACHINED PINION, 15T |
| 6670 | PRECISION MACHINED PINION, 16T |
| 6951 | 4-40 X 1/8" SET SCREW, with wrench |
| 8280 | 75 TOOTH, 48 PITCH |
| 8281 | 78 TOOTH, 48 PITCH |
| 8282 | 81 TOOTH, 48 PITCH |
| 8283 | 83 TOOTH, 48 PITCH |
| 8284 | 85 TOOTH, 48 PITCH |
| 8285 | 87 TOOTH, 48 PITCH |
| 8252 | 15 TOOTH, 48 PITCH |
| 8253 | 16 TOOTH, 48 PITCH |
| 8254 | 17 TOOTH, 48 PITCH |
| 8255 | 18 TOOTH, 48 PITCH |
| 8256 | 19 TOOTH, 48 PITCH |
| 8257 | 20 TOOTH, 48 PITCH |
| 8258 | 21 TOOTH, 48 PITCH |
| 8259 | 22 TOOTH, 48 PITCH |
| 8260 | 23 TOOTH, 48 PITCH |
| 8261 | 24 TOOTH, 48 PITCH |
| 8262 | 25 TOOTH, 48 PITCH |
| 8263 | 26 TOOTH, 48 PITCH |
| 6693 | 81 TOOTH, 48 PITCH |
| 6694 | 85 TOOTH, 48 PITCH |
| 6695 | 87 TOOTH, 48 PITCH |
| 8125 | ON ROAD FRONT WHEEL, (uses #6902 ball bearing for RC10) |
| 8125B | ON ROAD FRONT WHEEL, black (uses #6902 ball bearing for RC10) |
| 8125Y | ON ROAD FRONT WHEEL, fluorescent yellow (uses #6902 ball bearing for RC10) |
| 8126 | ON ROAD FRONT WHEEL, chrome finish, (uses #6902 ball bearing for RC10) |
| 6902 | BALL BEARING, for one front wheel |
| 8130 | FRONT TIRE DONUT, Green |
| 8131 | FRONT TIRE DONUT, Black |
| 8132 | ATLANTIC GOMME rubber, front, unmounted |
| 8140 | ON ROAD FRONT WHEEL/TIRE, Green compound, mounted and trued, (uses #6902 ball bearing for RC10) |
| 8141 | ON ROAD FRONT WHEEL/TIRE, Black compound, mounted & trued, (uses #6902 ball bearing for RC10) |
.avif)
.avif)
