Tekno ET48 2.0 Manual

Commonly replaced parts

What gets replaced most often — full list below.

Part #	Description
TKR9048A (opens in new tab)	Spindle Carriers (revised, L/R, aluminum, 15 degree)
TKR9040 (opens in new tab)	Rear Hubs and Bearing Spacers (L/R)
TKR9018 (opens in new tab)	Front Bumper (2pcs)
TKRBB08165F (opens in new tab)	Ball Bearing (8X16x5mm, flanged, shielded, 4pcs)
TKR6009 (opens in new tab)	Shock O-Ring and Bladder Set (for 2 shocks)
TKR5187B (opens in new tab)	Rod Ends (hard, 6.8mm, 8pcs)
TKR9237 (opens in new tab)	Spur Gear (44T, composite)

See all 135 parts →

More option parts for this car

Parts & upgrades at AMainAD Diff oil chart Spring chart 1/8 truggy tire chart Shock oil chart

Free to start · iOS & Android

Your Tekno ET48 2.0 is in the RC Setup App

Save every setup change you make to your Tekno ET48 2.0, get AI tuning answers for that exact car, and log your races — at the track or back in the pits.

See what it does →

Tekno

ET48 2.0

Setup sheets →

ET48 2.0 parts & upgrades at AMain →AD

For this car:ADESCs Motors

Email me about new:

SetupsKit & part deals

Dial in your setup

Diff oil chart Spring chart 1/8 truggy tire chart Shock oil chart

Manuals for other versions of this car:

ET48 2.2 Manual rev 05

Full parts list

Front End

Part #	Description
TKR8073 (opens in new tab)	CV Rebuild Kit (front/rear, for 2 axles)
TKR9018 (opens in new tab)	Front Bumper (2pcs)
TKR9041	Spindles and Bearing Spacers (L/R)
TKR9043 (opens in new tab)	Spindle Carrier Hinge Pins (steel, 4pcs)
TKR9048A (opens in new tab)	Spindle Carriers (revised, L/R, aluminum, 15 degree)
TKR9062	Chassis Brace Set (front/rear/center)
TKR9428	Shock Tower (front, 7075 CNC, GM ano)
TKR9436	Suspension Arms (front, 2pcs)
TKR9485 (opens in new tab)	Sway Bar Set (FRONT)

Rear End

Part #	Description
TKR9040 (opens in new tab)	Rear Hubs and Bearing Spacers (L/R)
TKR9165 (opens in new tab)	Rear Arm Hinge Pin Inserts
TKR9166 (opens in new tab)	Rear Hub Roll Center Inserts
TKR9429	Shock Tower (rear, 7075 CNC, GM ano)
TKR9430	Suspension Arms (rear, 2pcs)
TKR9495 (opens in new tab)	Sway Bar Set (REAR)

Suspension

Part #	Description
TKR5049A (opens in new tab)	Pivot Balls (6.8mm, no flng, sway bar, shck ends, almnm, 4pcs)
TKR5079A (opens in new tab)	Stabilizer Balls (6.8mm, sway bars, aluminum, 4pcs)
TKR5165 (opens in new tab)	V2 Hinge Pin Inserts, Wheelbase Shims
TKR5187B (opens in new tab)	Rod Ends (hard, 6.8mm, 8pcs)
TKR6140C (opens in new tab)	Locking Shock Rod End and Spring Perch Set (revised)
TKR8052A (opens in new tab)	Pivot Balls (6.8mm, camber, str links, almnm, centered, 4pcs)
TKR9017	Sway Bar and Bulkhead Acc
TKR9020 (opens in new tab)	Hinge Pins (inner, front/rear)
TKR9034 (opens in new tab)	Hinge Pins (outer, rear, 2pcs)
TKR9055 (opens in new tab)	Hinge Pin Bushings (8pcs)
TKR9423 (opens in new tab)	Turnbuckle (M4 thread, 100mm length, 4mm adjustment, 2pcs)
TKR9450 (opens in new tab)	Turnbuckle (M5 thread, 108mm length, 5mm adjustment, 2pcs)
TKR9461	Hinge Pin Brace (CNC, 7075, A Block)
TKR9462	Hinge Pin Brace (CNC, 7075, B Block)
TKR9463	Hinge Pin Brace (CNC, 7075, C Block)
TKR9464	Hinge Pin Brace (CNC, 7075, D Block)

Steering

Part #	Description
TKR1250 (opens in new tab)	Steering Link Screws (black, steel, 2pcs)
TKR5101X (opens in new tab)	Servo Saver Spring (HD)
TKR5103 (opens in new tab)	Servo Saver Post (aluminum, gun metal ano)
TKR5122 (opens in new tab)	Steering Rack Bushings (aluminum, gun metal ano, 2pcs)
TKR5230 (opens in new tab)	Steering Linkage (M3x18mm threaded rod, 10pcs)
TKR5231 (opens in new tab)	Servo Saver Nut and Spring
TKR8100B (opens in new tab)	Ackerman Plate (7075)
TKR9102A (opens in new tab)	Steering Posts (aluminum, gun metal ano)
TKR9104 (opens in new tab)	Bell Cranks and Top Plate

Drivetrain

Part #	Description
TKR8070 (opens in new tab)	Stub Axles (hardened steel, 2pcs)
TKR9011 (opens in new tab)	Motor Mount Insert (7075, gun metal ano)
TKR9191 (opens in new tab)	Tapered Driveshaft (center, front, 7075, black ano)
TKR9237 (opens in new tab)	Spur Gear (44T, composite)
TKR9412 (opens in new tab)	Gearbox (front)
TKR9416	Gearbox (rear)
TKR9472 (opens in new tab)	Driveshafts (F/R, hardened steel, 2pcs)
TKR9676 (opens in new tab)	Universal Driveshaft (center, rear)

Differentials

Part #	Description
TKR1222 (opens in new tab)	13x16x.1mm Diff Shims (10pcs)
TKR5144	Differential O-Rings (6pcs)
TKR5145B (opens in new tab)	Differential Shims (revised, 6x17mm, 6pcs)
TKR9010 (opens in new tab)	Split Center Diff Mount (7075, gun metal ano)
TKR9114 (opens in new tab)	Differential Outdrives (F/R NB/NT48 2.0, F/C/R EB/ET48 2.0, 2pcs)
TKR9115	Differential Case (F/R NB/NT48 2.0, F/C/R EB/ET48 2.0)
TKR9143 (opens in new tab)	Differential Seals (3pcs)
TKR9149 (opens in new tab)	Differential Cross Pins (6pcs)
TKR9150	Differential Gear Set (internal gears only)
TKR9262 (opens in new tab)	Split Center Diff Mount (composite, requires TKR9010)
TKR9452 (opens in new tab)	Differential Ring Gear (40t, F/R, CNC, use with TKR9453)
TKR9453 (opens in new tab)	Diff Pinion (9t, F/R, CNC, use with TKR9452)

Brakes

Part #	Description
TKR5058A (opens in new tab)	Pivot Balls (5.8mm, no flange, brake/steering link, aluminum, 4pcs)
TKR9059 (opens in new tab)	Rod End Set (brake/steering/sway bar linkage)

Wheels & Hubs

Part #	Description
TKR5116 (opens in new tab)	Wheel Nuts (17mm, serrated, gun metal ano, M12x1.0, 4pcs)
TKR9671 (opens in new tab)	Wheel Hubs (+2mm offset, 17mm, gun metal ano, w/pins, 2pcs)
TKR9673 (opens in new tab)	Wheel Hubs (+4mm offset, 17mm, gun metal ano, w/pins, 2pcs)

Chassis & Body

Part #	Description
TKR1235 (opens in new tab)	Body Clips (10pcs)
TKR8292W (opens in new tab)	Lightweight Wing (ROAR/IFMAR legal, white)
TKR9024 (opens in new tab)	Mud Guard Set (L/R)
TKR9181T (opens in new tab)	Tall Wing Mount and Body Mounts
TKR9445N (opens in new tab)	Headlights / Nose Cone
TKR9601 (opens in new tab)	Chassis (7075, hard anodized)
TKR9645A (opens in new tab)	Body (w/ window mask)
TKR9646 (opens in new tab)	Decal Sheet

Electronics

Part #	Description
TKR5126 (opens in new tab)	Antenna tube (universal, w/ caps, 5pcs)
TKR9019 (opens in new tab)	Battery Straps (1x center, 1x side)
TKR9026 (opens in new tab)	Battery Strap Mounts
TKR9065 (opens in new tab)	Servo Mount, ESC tray, RX Box

Shocks

Part #	Description
TKR1240 (opens in new tab)	Lower Shock Mount Screws (2 CW thread, 2 CCW thread)
TKR6009 (opens in new tab)	Shock O-Ring and Bladder Set (for 2 shocks)
TKR6013 (opens in new tab)	Shock Adjustment Nuts (aluminum, gun metal ano, 2pcs)
TKR6015 (opens in new tab)	Shock Cartridge Caps (aluminum, gun metal ano, 2pcs)
TKR6016 (opens in new tab)	Shock Body (rear, aluminum, hard ano, 2pcs)
TKR6017 (opens in new tab)	Shock Shafts (rear, steel, 2pcs)
TKR6060 (opens in new tab)	Shock Body (rear, x-long, aluminum, hard ano, 2pcs)
TKR6061 (opens in new tab)	Shock Shafts (rear, x-long, steel, 2pcs)
TKR6144 (opens in new tab)	Shock Boots (long length, 2pcs)
TKR6145 (opens in new tab)	Shock Boots (XL length, rear ET/NT, 2pcs)
TKR6146	Shock Cartridge Set (CNC, Delrin)
TKR6180 (opens in new tab)	Shock Piston (CNC, flat/flat, 4x1.2 + 4x1.3)
TKR8702 (opens in new tab)	Shock Caps (7075, emulsion/vented/standard, black ano, 2pcs)
TKR8725 (opens in new tab)	Emulsion O-ring Set (4x cap seals, 8x emulsion o-rings, for 16mm shocks)
TKR8727	Shock Standoffs (2pcs, requires TKR8730)
TKR8730 (opens in new tab)	Shock Cap Bushings (4pcs, requires TKR8727)

Bearings

Part #	Description
TKRBB050825	Ball Bearing (5x8x2.5mm, 4pcs)
TKRBB05104 (opens in new tab)	Ball Bearing (5x10x4, 4pcs)
TKRBB05114 (opens in new tab)	Ball Bearing (5x11x4, 4pcs)
TKRBB05145 (opens in new tab)	Ball Bearing (5x14x5, shielded, 4pcs)
TKRBB06103 (opens in new tab)	Ball Bearing (6x10x3, 4pcs)
TKRBB08165 (opens in new tab)	Ball Bearing (8x16x5, 4pcs)
TKRBB08165F (opens in new tab)	Ball Bearing (8X16x5mm, flanged, shielded, 4pcs)
TKRBB15214 (opens in new tab)	Ball Bearing (15x21x4, shielded, 4pcs)

Hardware

Part #	Description
TKR1200 (opens in new tab)	M2.5 Locknuts (zinc finish, 10pcs)
TKR1201 (opens in new tab)	M3 Locknuts (black, 10pcs)
TKR1211 (opens in new tab)	M3 Locknuts (flanged, black, 10pcs)
TKR1212 (opens in new tab)	M4 Locknuts (flanged, black, serrated, 10pcs)
TKR1220 (opens in new tab)	M3 Countersunk Washers (aluminum, natural, 10pcs)
TKR1221 (opens in new tab)	M3x8mm Washer (black, 10pcs)
TKR1226 (opens in new tab)	5x7x.2mm shims (10pcs)
TKR1228 (opens in new tab)	M4 Countersunk Washer (black, 10pcs)
TKR1238 (opens in new tab)	Droop Adjustment Screws (M4x10mm, 8pcs)
TKR1248 (opens in new tab)	M2x4mm Cap Head Screws (black, 10pcs)
TKR1301 (opens in new tab)	M2.5x6mm Flat Head Screws (black, 10pcs)
TKR1324 (opens in new tab)	M3x12mm Flat Head Screws (black, 10pcs)
TKR1325 (opens in new tab)	M3x14mm Flat Head Screws (black, 10pcs)
TKR1343 (opens in new tab)	M4x10mm Flat Head Screws (black, 10pcs)
TKR1344 (opens in new tab)	M4x12mm Flat Head Screws (black, 10pcs)
TKR1346 (opens in new tab)	M4x15mm Flat Head Screws (black, 10pcs)
TKR1349 (opens in new tab)	M4x20mm Flat Head Screws (black, 10pcs)
TKR1401 (opens in new tab)	M3x6mm Button Head Screws (black, 10pcs)
TKR1402 (opens in new tab)	M3x8mm Button Head Screws (black, 10pcs)
TKR1403 (opens in new tab)	M3x10mm Button Head Screws (black, 10pcs)
TKR1407 (opens in new tab)	M3x16mm Button Head Screws (black, 10pcs)
TKR1443 (opens in new tab)	M4x10mm Button Head Screws (black, 10pcs)
TKR1444 (opens in new tab)	M4x12mm Button Head Screws (black, 10pcs)
TKR1445 (opens in new tab)	M4x14mm Button Head Screws (black, 10pcs)
TKR1523 (opens in new tab)	M3x10mm Cap Head Screws (black, 10pcs)
TKR1524 (opens in new tab)	M3x12mm Cap Head Screws (black, 10pcs)
TKR1525 (opens in new tab)	M3x14mm Cap Head Screws (black, 10pcs)
TKR1528 (opens in new tab)	M3x18mm Cap Head Screws (black, 10pcs)
TKR1529 (opens in new tab)	M3x20mm Cap Head Screws (black, 10pcs)
TKR1534 (opens in new tab)	M3x22mm Cap Head Screws (black, 10pcs)
TKR1601 (opens in new tab)	M3x4mm Set Screws (black, 10pcs)
TKR1603 (opens in new tab)	M5x4mm Set Screws (black, 10pcs)
TKR1605 (opens in new tab)	M3x10mm Set Screws (black, 10pcs)
TKR8042 (opens in new tab)	Kingpin Shoulder Screws (EB/NB48.4, 4pcs)
