Tekno ET48 2.2 Manual rev 05

Full parts list

Front end

Part #	Description
TKR5101X	Servo Saver Spring (HD)
TKR5103	Servo Saver Post (aluminum, gun metal ano)
TKR5122	Steering Rack Bushings (aluminum, 2pcs)
TKR5231	Servo Saver Nut and Spring
TKR8100C	Ackerman Plate (7075)
TKR9018	Front Bumper (2pcs)
TKR9043	Spindle Carrier Hinge Pins (steel, 4pcs)
TKR9047F	Spindle Arms (Type F)
TKR9057B	Spindle Pin/Sleeve Set (revised)
TKR9102A	Steering Posts (aluminum, 2pcs)
TKR9104	Bell Cranks and Top Plate
TKR9141B	Adjustable Ackerman Spindles (-2mm)
TKR9142B	Spindle Carriers (L/R, 18°, aluminum)
TKR9428B	Shock Tower (front, lightened, 7075 CNC, gun metal)
TKR9436B	Suspension Arms (front, 2pcs)
TKR9461B	Hinge Pin Brace (A Block, -1mm)
TKR9462B	Hinge Pin Brace (B Block, -1mm)
TKR9463B	Hinge Pin Brace (C Block, -1mm)
TKR9464B	Hinge Pin Brace (D Block, -1mm)
TKR9485	Sway Bar Set (front, 2.1–2.5mm)

Rear end

Part #	Description
TKR9034	Hinge Pins (outer, rear, 2pcs)
TKR9054B	Rear Hubs (-2mm, L/R)
TKR9429B	Shock Tower (rear, lightened, 7075 CNC, gun metal)
TKR9430B	Suspension Arms (rear, 2pcs)
TKR9495	Sway Bar Set (rear, 2.1–2.5mm)

Steering & suspension linkage

Part #	Description
TKR5049A	Pivot Balls (6.8mm, sway bar/shock ends, aluminum, 4pcs)
TKR5058A	Pivot Balls (5.8mm, brake/steering link, aluminum, 4pcs)
TKR5079A	Stabilizer Balls (6.8mm, sway bars, aluminum, 4pcs)
TKR5165	V2 Hinge Pin Inserts, Wheelbase Shims
TKR5187B	Rod Ends (hard, 6.8mm, 8pcs)
TKR8052A	Pivot Balls (6.8mm, camber/steering links, centered, 4pcs)
TKR9017B	Sway Bar and Bulkhead Accessories (-2/-4mm bulkheads)
TKR9020	Hinge Pins (inner, front/rear)
TKR9055	Hinge Pin Bushings (8pcs)
TKR9055C	Hinge Pin Bushings (long, 8pcs)
TKR9059C	Rod End Set (camber/sway bar, offset steering links)
TKR9290	Sway Bar Dead Band Bushing Set (2.4/2.7/3.0/3.3mm)
TKR9423	Turnbuckle (M4, 100mm, 2pcs)
TKR9450	Turnbuckle (M5, 108mm, 2pcs)

Driveline

Part #	Description
TKR9191	Tapered Driveshaft (center, front, 7075)
TKR9487	Universal Driveshaft Set (front/rear, 144mm, 2pcs)
TKR9676	Universal Driveshaft (center, rear)
TKR9687	Universal Driveshaft Set (rear only, 140mm, 2pcs)

Differentials

Part #	Description
TKR5075	Diff Coupler (rear, lightened, hardened steel)
TKR5144B	Differential O-Rings (6pcs)
TKR5145B	Differential Shims (revised, 6x17mm, 6pcs)
TKR9010	Split Center Diff Mount (7075, gun metal ano)
TKR9114	Differential Outdrives (front/rear/center, 2pcs)
TKR9115B	Differential Case (front/rear/center)
TKR9143	Differential Seals (3pcs)
TKR9149	Differential Cross Pins (6pcs)
TKR9150B	Differential Gear Set (internal gears, 20/10T)
TKR9237	Spur Gear (44T, composite)
TKR9262	Split Center Diff Mount (composite, requires TKR9010)
TKR9452	Differential Ring Gear (40T, CNC, use with TKR9453)
TKR9453	Diff Pinion (9T, CNC, use with TKR9452)

Shocks

Part #	Description
TKR6009	Shock O-Ring and Bladder Set (for 2 shocks)
TKR6013	Shock Adjustment Nuts (aluminum, gun metal, 2pcs)
TKR6015	Shock Cartridge Caps (aluminum, gun metal, 2pcs)
TKR6016	Shock Body (rear, aluminum, hard ano, 2pcs)
TKR6017	Shock Shafts (rear, steel, 2pcs)
TKR6060	Shock Body (x-long, aluminum, hard ano, 2pcs)
TKR6061	Shock Shafts (x-long, rear, steel, 2pcs)
TKR6136	Shock Piston Set (flat/flat, 6x1.2mm, 4pcs)
TKR6137	Shock Piston Set (flat/flat, 6x1.3mm, 4pcs)
TKR6140C	Locking Shock Rod End and Spring Perch Set
TKR6144	Shock Boots (long, 2pcs)
TKR6145	Shock Boots (x-long, rear, 2pcs)
TKR6195	Shock Shaft Guide Set (precision molded, POM)
TKR8702	Shock Caps (7075, emulsion/vented/standard, black ano, 2pcs)
TKR8725	Emulsion O-Ring Set (4x cap seals, 8x emulsion o-rings)
TKR8730	Shock Cap Bushings (4pcs, requires TKR8727)
TKR8777	Shock Standoffs (+0mm, requires TKR1443, 2pcs)
TKR8777B	Shock Standoffs (+2mm, requires TKR1443, 2pcs)

Drivetrain

Part #	Description
TKR9011	Motor Mount Insert (7075, gun metal ano)
TKR9416B	Gearbox (-2mm, front/rear)

Chassis & body

Part #	Description
TKR5401	Body Mount Set
TKR6686	Body Mount Hook and Loop Tape Set (4pcs)
TKR8292W	Lightweight Wing (ROAR/IFMAR legal, white)
TKR9024	Mud Guard Set (L/R)
TKR9062B	Chassis Brace Set (revised, front/rear/center)
TKR9181T	Tall Wing Mount and Body Mounts
TKR9445N	Headlights / Nose Cone
TKR9606	Chassis (7075, hard anodized)
TKR9645A	Body (w/ window mask)

Electronics

Part #	Description
TKR5126	Antenna Tube (universal, w/ caps, 5pcs)
TKR9019	Battery Straps (1x center, 1x side)
TKR9026	Battery Strap Mounts
TKR9065	Servo Mount, ESC Tray, RX Box
TKR9553M	Metal Servo Horn (25T spline)

Wheels & hubs

Part #	Description
TKR5116	Wheel Nuts (17mm, serrated, gun metal, 4pcs)
TKR9671	Wheel Hubs (+2mm offset, 17mm, gun metal, w/pins, 2pcs)
TKR9673	Wheel Hubs (+4mm offset, 17mm, gun metal, w/pins, 2pcs)

Bearings

Part #	Description
TKRBB050825RS	Ball Bearing (5x8x2.5mm, rubber shielded, 4pcs)
TKRBB05145	Ball Bearing (5x14x5mm, shielded, 4pcs)
TKRBB06103	Ball Bearing (6x10x3mm, 4pcs)
TKRBB08165	Ball Bearing (8x16x5mm, 4pcs)
TKRBB08165F	Ball Bearing (8x16x5mm, flanged, shielded, 4pcs)
TKR12215	Ball Bearing (12x21x5mm, shielded, 4pcs)

Hardware

Part #	Description
TKR1200	M2.5 Locknuts (zinc finish, 10pcs)
TKR1201	M3 Locknuts (black, 10pcs)
TKR1211	M3 Locknuts (flanged, black, 10pcs)
TKR1220	M3 Countersunk Washers (aluminum, natural, 10pcs)
TKR1221	M3x8mm Washer (black, 10pcs)
TKR1226	5x7x.2mm Shims (10pcs)
TKR1228	M4 Countersunk Washer (black, 10pcs)
TKR1235	Body Clips (10pcs)
TKR1238	Droop Adjustment Screws (M4x10mm, 8pcs)
TKR1240	Lower Shock Mount Screws (2 CW, 2 CCW)
TKR1248	M2x4mm Cap Head Screws (black, 10pcs)
TKR1264	M2.6x6.0x0.5mm Washer (black, 10pcs)
TKR1301	M2.5x6mm Flat Head Screws (black, 10pcs)
TKR1324	M3x12mm Flat Head Screws (black, 10pcs)
TKR1325	M3x14mm Flat Head Screws (black, 10pcs)
TKR1327	M3x16mm Flat Head Screws (black, 10pcs)
TKR1343	M4x10mm Flat Head Screws (black, 10pcs)
TKR1344	M4x12mm Flat Head Screws (black, 10pcs)
TKR1346	M4x15mm Flat Head Screws (black, 10pcs)
TKR1349	M4x20mm Flat Head Screws (black, 10pcs)
TKR1401	M3x6mm Button Head Screws (black, 10pcs)
TKR1402	M3x8mm Button Head Screws (black, 10pcs)
TKR1403	M3x10mm Button Head Screws (black, 10pcs)
TKR1404	M3x12mm Button Head Screws (black, 10pcs)
TKR1420	M3x5mm Button Head Screws (black, 10pcs)
TKR1443	M4x10mm Button Head Screws (black, 10pcs)
TKR1444	M4x12mm Button Head Screws (black, 10pcs)
TKR1445	M4x14mm Button Head Screws (black, 10pcs)
TKR1447	M4x16mm Button Head Screws (black, 10pcs)
TKR1523	M3x10mm Cap Head Screws (black, 10pcs)
TKR1524	M3x12mm Cap Head Screws (black, 10pcs)
TKR1525	M3x14mm Cap Head Screws (black, 10pcs)
TKR1528	M3x18mm Cap Head Screws (black, 10pcs)
TKR1529	M3x20mm Cap Head Screws (black, 10pcs)
TKR1530	M3x25mm Cap Head Screws (black, 10pcs)
TKR1534	M3x22mm Cap Head Screws (black, 10pcs)
TKR1601	M3x4mm Set Screws (black, 10pcs)
TKR1603	M5x4mm Set Screws (black, 10pcs)
TKR1605	M3x10mm Set Screws (black, 10pcs)
TKR5230	Steering Linkage (M3x18mm threaded rod, 10pcs)
