Slash Late Model

Traxxas Slash Late Model

Q&A, gearing, kit settings, manual, and guides

Oval•Late Model•1/10 scale•2WD

Ask Miles, our Setup AI that’s been trained on the Slash Late Model.

Setups

Get Slash Late Model alerts
Be the first to share a setup for the Slash Late Model
Upload your sheet, we fill in the details
Add your setup

Gearing

Stock gearing for the Traxxas Slash Late Model, with common pinions and their ratios.

Stock spur
86T
Internal ratio
2.72:1
Typical pinion
20–27T
1/10 2WD late model setups. For your motor and track →
PinionSpur ÷ pinionFDRRollout
18T4.7813.0016.6 mm
19T4.5312.3117.5 mm
20T4.3011.7018.4 mm
21T4.1011.1419.3 mm
22T3.9110.6320.3 mm
23T3.7410.1721.2 mm
24T3.589.7522.1 mm
25T3.449.3623.0 mm
26T3.319.0024.0 mm
27T3.198.6624.9 mm
28T3.078.3525.8 mm
29T2.978.0726.7 mm

Shaded rows are the pinions most 1/10 2WD late model setups run on the stock spur. Rollout at a 68.6 mm tire.

What pinion should I run?

Tell us your motor and track and get a starting pinion for the Traxxas Slash Late Model, with the range racers in the class run.

Get a recommendation →Shop pinion gears at AMain → (opens in new tab)

What pinion gear should I use on the Traxxas Slash Late Model?

It depends on your motor and the track. Racers in the 1/10 2WD late model class run a 20–27 tooth pinion in most setups, usually on a 81T spur for a final drive ratio near 8.81. Hotter motors (lower turns, higher Kv) take a smaller pinion; tight tracks gear down, open tracks gear up. For a starting pinion matched to your motor, use the So Dialed Pinion Recommender with the Slash Late Model selected.

What is the internal ratio (transmission ratio) of the Traxxas Slash Late Model?

The Slash Late Model has an internal ratio of 2.72:1. Final drive ratio = spur ÷ pinion × 2.72. With the stock 86T spur, a 18T pinion gives an FDR of 13.00 and a 29T gives 8.07.

How many teeth is the stock spur gear on the Traxxas Slash Late Model?

86 teeth. Changing the spur moves every pinion's ratio at once; most racers leave the spur and tune with the pinion.

Kit setup

Kit shock setup. Part numbers link to AMain.

Shock oil
Front
50 wt
Rear
60 wt
Springs
Front
1.6lb Blue #5434 →
Rear
1.6lb Blue #5434 →
Pistons
Front
2-hole
Rear
2-hole

What shock oil does the Traxxas Slash Late Model come with?

Out of the box the Slash Late Model runs 50 wt front, 60 wt rear, on 2-hole front, 2-hole rear pistons. That is the kit setup; you will need to adjust it for your track conditions. The RC Setup App can help dial it in.

What springs does the Traxxas Slash Late Model come with?

The kit springs are 1.6lb Blue (#5434) front, 1.6lb Blue (#5434) rear. Stiffer springs suit high grip and big jumps; softer springs add grip on slick or bumpy tracks.
